RT15-660V/125A~300A Semiconductor Fuse
Home Products Stud Screw Fit ThyristorSemiconductor FusesRT15-660V/125A~300A Semiconductor Fuse
Product Details
RT15-660V/125A~300A Semiconductor Fuse
Usage and range
RT15 Series stud-connection fuse is applicable for AC 50Hz or 60Hz, rated voltage 660V, rated current 300A and the below industrial electrical device, which for over-load and short-circuit protection.
Specification
| Model | Rated voltage (V) | Rated current (A) | Rated breaking capacity | Rated consumption power (W) | Rated frequency |
| RT15 660V-125A | AC 660V | 125, 160, 200 | 50 KA | ≤17 | 50Hz or 60Hz |
| RT15 660V-160A | |||||
| RT15 660V-200A | |||||
| RT15 660V-300A | 300 | ≤32 |
