Phase Control Thyristor T242
Home Products Stud Screw Fit ThyristorStud Thyristor (Russian version)Phase Control Thyristor T242
Product Details
Phase Control Thyristor T242
Type | VDRM | IT(AV) | ITSM | VTM /ITM | V T(TO) | rT | (diT/ | duD/dt) cr | t q(typ) | R th(j-c) | TVJM | Md | Case |
VRRM | dt)cr | ||||||||||||
(TC,ºC) | 10ms | TVJM | TVJM | TVJM | TVJM | TVJM | |||||||
V | A | kA | V/A | V | mΩ | A/μs | V/μs | μs | ºC/W | ºC | Nm | ºC/W | |
T242-63 | 100-1600 | 63(95) | 1.3 | 1.60/198 | 0.95 | 4.1 | 125 | 50-1000 | 80 | 0.3 | 125 | 9.0-11 | ST4 |
T242-80 | 100-1600 | 80(87) | 1.5 | 1.65/250 | 0.93 | 3.3 | 125 | 50-1000 | 80 | 0.3 | 125 | 9.0-11 | ST4 |
