Phase Control Thyristor T232
Home Products Stud Screw Fit ThyristorStud Thyristor (Russian version)Phase Control Thyristor T232
Product Details
Phase Control Thyristor T232
| Type | VDRM | IT(AV) | ITSM | VTM /ITM | V T(TO) | rT | (diT/ | duD/dt) cr | t q(typ) | R th(j-c) | TVJM | Md | Case |
| VRRM | dt)cr | ||||||||||||
| (TC,ºC) | 10ms | TVJM | TVJM | TVJM | TVJM | TVJM | |||||||
| V | A | kA | V/A | V | mΩ | A/μs | V/μs | μs | ºC/W | ºC | Nm | ºC/W | |
| T232-40 | 100-1600 | 40(93) | 0.75 | 1.75/125 | 1.05 | 5.6 | 125 | 50-1000 | 80 | 0.5 | 125 | 5.3-5.7 | ST3 |
| T232-50 | 100-1600 | 50(85) | 0.8 | 1.75/157 | 1.03 | 4.6 | 125 | 50-1000 | 80 | 0.5 | 125 | 5.3-5.7 | ST3 |
