Product Details

Phase Control Thyristors 5STP series

The features of the 5STP series thyristors include the following:

High Voltage and Current Capability: These thyristors can handle high voltage and high current, making them suitable for high-power applications.
High Reliability: Designed to operate in harsh industrial environments, they offer high reliability and long lifespan.
Low Conduction Loss: They have a low voltage drop in the conducting state, reducing power loss and improving efficiency.
Fast Switching Capability: Capable of quickly responding to control signals for precise current control.
Excellent Thermal Performance: They have good thermal management characteristics, allowing stable operation in high-temperature environments.
Robust Structural Design: Featuring a sturdy package design, they can withstand mechanical and thermal stress.

These features make the 5STP series thyristors commonly used components in power electronic devices, widely applied in motor drives, rectifiers, inverters, and other high-power control scenarios.

Part Numbers

Type	IT(AV)M (Tc=70℃)	VDRM VRRM	ITSM	V_To	r_T	Tvj max	Rth(j-c)	Rth(c-h)	Fm ±10%
Type	A	V	kA	V	mΩ	℃	K/kW	K/kW	kN
5STP03X6500	340	6500	4.7	1.20	2.30	125	45	7.5	10
5STP03D6500	390	6500	4.7	1.20	2.30	125	36	7.5	10
5STP04D4200	500	4200	7.1	1.14	1.288	125	36	7.5	10
5STP04D5200	420	5200	6.1	1.29	1.917	125	36	7.5	10
5STP06T1600	640	1600	9.9	0.99	0.50	125	44	12.0	9
5STP06D2800	640	2800	8.8	0.92	0.78	125	36	7.5	10
5STP06T4200	598	4200	7.5	1.30	0.93	125	32	10.0	10
5STP06D4200	598	4200	7.5	1.30	0.93	125	32	10.0	10
5STP07D1800	760	1800	9.0	0.93	0.448	125	36	7.5	10
5STP08T2800	792	2800	10.6	1.06	0.49	125	32	10.0	10
5STP08D2801	793	2800	10.6	1.02	0.51	125	32	7.5	10
5STP08G6500	730	6500	15.1	1.20	1.046	125	22	4.0	22
5STP08F6500	850	6500	15.1	1.20	1.046	125	17	4.0	22
5STP09D1801	932	1800	13.7	0.94	0.34	125	32	7.5	10
5STP09D2201	862	2200	12.0	1.00	0.40	125	32	7.5	10
5STP10T1600	969	1600	15.0	0.93	0.30	125	32	10.0	10
5STP10D1601	969	1600	15.0	0.93	0.30	125	32	7.5	10
5STP12F4200	1190	4200	17.3	1.01	0.545	125	17	4.0	22
5STP12F4201	1247	4200	15.0	1.25	0.42	125	16	4.0	22
5STP12F4240	1247	4200	15.0	1.25	0.42	125	16	4.0	22
5STP12K6500	1430	6500	31.5	1.15	0.647	125	11	2.0	50
5STP15T2800	1589	2800	23.6	1.02	0.26	125	15.5	4.0	22
5STP16F2800	1500	2800	18.0	0.96	0.297	125	17	4.0	22
5STP16F2801	1512	2800	23.6	1.02	0.26	125	16	4.0	22
5STP16F2810	1500	2800	18.0	0.96	0.297	125	17	4.0	22
5STP17T2200	1743	2200	25.5	0.99	0.20	125	15.5	4.0	22
5STP17F2201	1702	2200	25.5	0.99	0.20	125	16	4.0	22
5STP17H5200	1970	5200	34.0	0.99	0.343	125	10	2.0	50
5STP18F1800	1780	1800	21.0	0.92	0.188	125	17	4.0	22
5STP18T1800	1870	1800	26.2	0.96	0.17	125	15.5	4.0	22
5STP18F1801	1825	1800	26.2	0.97	0.17	125	16	4.0	22
5STP18F1810	1780	1800	21.0	0.92	0.188	125	17	4.0	22
5STP18H4200	2170	4200	32.0	0.98	0.274	125	10	2.0	50
5STP18M6500	1830	6500	47.5	1.21	0.431	125	9.0	1.5	70
5STP20T1600	1956	1600	27.3	0.95	0.15	125	15.5	4.0	22
5STP20F1601	1901	1600	27.3	0.95	0.15	125	16	4.0	22
5STP20N8500	2000	8500	35.0	1.25	0.48	115	5.7	1.0	90
5STP21H4200	2192	4200	32.0	1.25	0.19	125	10	3.0	50
5STP21H4240	2192	4200	32.0	1.25	0.19	125	10	3.0	50
5STP24H2800	2780	2800	43.0	0.93	0.141	125	10	2.0	50
5STP25M5200	2400	5200	50.5	0.99	0.237	125	9.0	1.5	70
5STP25L5200	2830	5200	50.5	0.99	0.237	125	7.0	1.5	70
5STP26N6500	2880	6500	65.0	1.12	0.29	125	5.7	1.0	90
5STP27H1800	2940	1800	50.5	0.91	0.096	125	10	2.0	50
5STP27T2800	2670	2800	43.0	1.04	0.12	125	10	3.0	50
5STP27H2801	2670	2800	43.0	1.04	0.12	125	10	3.0	50
5STP27N8500	2660	8500	64.0	1.13	0.394	125	5.7	1.0	90
5STP27Q8500	2870	8500	64.0	1.13	0.394	125	5.0	1.0	90
5STP28L4200	3290	4200	54.0	1.03	0.138	125	7.0	1.5	70
5STP29T2200	2855	2200	45.0	1.00	0.10	125	10	3.0	50
5STP29H2201	2855	2200	45.0	1.00	0.10	125	10	3.0	50
5STP30T1800	3108	1800	47.0	0.98	0.08	125	10	3.0	50
5STP30H1801	3108	1800	47.0	0.98	0.08	125	10	3.0	50
5STP33L2800	3760	2800	65.5	0.93	0.10	125	7.0	1.5	70
5STP34T1600	3370	1600	49.0	0.94	0.06	125	10	3.0	50
5STP34H1601	3370	1600	49.0	0.94	0.06	125	10	3.0	50
5STP34N5200	3450	5200	63.0	0.96	0.194	125	5.7	1.0	90
5STP34Q5200	3720	5200	63.0	0.96	0.194	125	5.0	1.0	90
5STP38N4200	4090	4200	64.5	0.97	0.126	125	5.7	1.0	90
5STP38Q4200	4420	4200	64.5	0.97	0.126	125	5.0	1.0	90
5STP40N6500	3780	6500	75.0	1.14	0.255	135	4.8	1.0	90
5STP42L1800	4310	1800	64.0	0.81	0.08	125	7.0	1.5	70
5STP42U6500	4300	6500	86.0	1.17	0.181	125	4.0	0.8	135
5STP45N2800	5250	2800	77.0	0.86	0.069	125	5.7	1.0	90
5STP45Q2800	5710	2800	77.0	0.86	0.069	125	5.0	1.0	90
5STP45Y8500	4450	8500	90.0	1.06	0.168	110	3.0	0.6	190
5STP48Y7200	5040	7200	92.0	0.98	0.128	110	3.0	0.6	190
5STP50Q1800	6100	1800	94.0	0.90	0.05	125	5.0	1.0	90
5STP52U5200	5200	5200	99.0	1.04	0.115	125	4.0	0.8	135
