General purpose Diodes
Home Products Disc PCT and RectifierCapsule type Rectifier DiodesGeneral purpose Diodes
General purpose Diodes
Type |
IF(AV) |
VRRM |
IFSM@ TVJM & 10ms |
IRRM (max)& Tj=Tjmax |
VFM (max)@ |
Tvj |
Rthjc |
F±10% |
Outline |
||
A |
V |
KA |
mA |
V |
A |
℃ |
℃ |
K/W |
KN |
||
A540 |
1000 |
2000-4000 |
12 |
35 |
1.08 |
1000 |
160 |
185 |
0.05 |
13 |
ZT33 |
A640 |
1500 |
1200-2200 |
16 |
35 |
1.09 |
1000 |
25 |
185 |
0.04 |
15 |
ZT40 |
A641 |
1500 |
1800-2600 |
15 |
70 |
1.09 |
1000 |
25 |
185 |
0.04 |
15 |
ZT40 |
A643 |
1000 |
3600-4600 |
10 |
50 |
1.40 |
1000 |
160 |
170 |
0.04 |
15 |
ZT40 |
A740 |
2400 |
1400-2000 |
30 |
50 |
0.86 |
1000 |
160 |
185 |
0.02 |
25 |
ZT55 |
A750 |
1800 |
2400-3200 |
22 |
50 |
0.96 |
1000 |
160 |
175 |
0.02 |
25 |
ZT55 |
A780 |
1500 |
3500-4600 |
18 |
50 |
1.15 |
1000 |
160 |
170 |
0.02 |
25 |
ZT55 |
A800 |
4400 |
1800-2600 |
63 |
100 |
0.865 |
2000 |
160 |
185 |
0.01 |
36 |
ZT80 |
A801 |
3900 |
2800-3200 |
57 |
100 |
1.05 |
2000 |
160 |
175 |
0.01 |
36 |
ZT80 |
A880 |
2900 |
3600-4500 |
36 |
100 |
1.15 |
2000 |
160 |
170 |
0.01 |
36 |
ZT80 |
