Thyristor Diode Module MDT MTD
Home Products Thyristor Diode ModuleThyristor Diode Module Basic VersionThyristor Diode Module MDT MTD
Part numbers list
Thyristor Diode Module MDT MTD
| Type | IT(AV)M | VRRM | ITSM | tq | V(TO) | rT | VTM | ITM | Tvj max | Rth(j−c) | W | Package, Dimensions L×B×H |
| A | V | kA | μs | V | mΩ | V | A | ℃ | ℃/W | g | mm | |
| MTD3 | ||||||||||||
| MTD3-115-36-F | 115 (85) | 3000-3600 | 2.5 | 400 | 0.95 | 3.000 | 2.45 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MTD3-130-28-F | 130 (85) | 2400-2800 | 3.4 | 250 | 0.85 | 2.400 | 1.80 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MTD3-160-36-C1 | 160 (88) | 3000-3600 | 4.0 | 400 | 1.20 | 2.300 | 2.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD3-165-22-F | 165 (85) | 2000-2200 | 4.7 | 160 | 0.80 | 1.350 | 1.50 | 500 | 125 | 0.1800 | 0.35 | F 94x34x30 |
| MTD3-200-28-C1 | 200 (93) | 2600-2800 | 5.5 | 250 | 0.90 | 1.100 | 2.00 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD3-201-18-F | 201 (85) | 1000-1800 | 6.0 | 125 | 0.80 | 0.970 | 1.40 | 500 | 130 | 0.1800 | 0.35 | F 94x34x30 |
| MTD3-240-65-A2 | 240 (85) | 4600-6500 | 4.0 | 630 | 1.10 | 2.500 | 2.10 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD3-250-24-C1 | 250 (91) | 2000-2400 | 7.6 | 200 | 0.80 | 0.700 | 1.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD3-260-44-A2 | 260 (85) | 3800-4400 | 5.0 | 500 | 1.40 | 1.300 | 2.30 | 628 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD3-320-18-C1 | 320 (90) | 1000-1800 | 8.5 | 160 | 0.75 | 0.500 | 1.40 | 785 | 130 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD3-320-36-A2 | 320 (85) | 3000-3600 | 5.5 | 320 | 1.15 | 0.800 | 2.20 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD3-400-28-A2 | 400 (82) | 2600-2800 | 9.0 | 250 | 1.00 | 0.650 | 1.80 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD3-400-44-D | 400 (88) | 3800-4400 | 14.0 | 500 | 1.20 | 0.650 | 2.70 | 2512 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD3-430-24-A2 | 430 (85) | 2000-2400 | 12.0 | 250 | 1.00 | 1.410 | 1.55 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD3-500-36-D | 500 (85) | 3000-3600 | 18.0 | 400 | 1.10 | 0.400 | 1.85 | 1570 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD3-540-18-A2 | 540 (85) | 1400-1800 | 15.5 | 250 | 0.85 | 0.320 | 1.50 | 1570 | 130 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD3-595-18-A2 | 595 (85) | 1400-1800 | 17.5 | 320 | 0.84 | 0.310 | 1.50 | 1570 | 135 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD3-630-28-D | 630 (80) | 2600-2800 | 21.0 | 320 | 0.95 | 0.300 | 1.40 | 1978 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD3-650-12-A2 | 650 (85) | 1000-1200 | 14.0 | 160 | 0.85 | 0.280 | 1.40 | 1978 | 140 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD3-740-24-D | 740 (77) | 2000-2400 | 24.5 | 320 | 0.90 | 0.210 | 1.55 | 3140 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD3-800-18-D | 800 (78) | 1400-1800 | 28.0 | 250 | 0.85 | 0.230 | 1.45 | 2512 | 130 | 0.0500 | 4.1 | D 150x77x84 |
| MTD3-1000-12-D | 1000 (77) | 1000-1200 | 32.0 | 200 | 0.90 | 0.150 | 1.25 | 3140 | 140 | 0.0500 | 4.1 | D 150x77x84 |
| MTD3-1250-8-D | 1250 (77) | 100-800 | 34.0 | 160 | 0.80 | 0.120 | 1.20 | 3925 | 150 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3 | ||||||||||||
| MDT3-115-36-F | 115 (85) | 3000-3600 | 2.5 | 400 | 0.95 | 3.000 | 2.45 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MDT3-130-28-F | 130 (85) | 2400-2800 | 3.4 | 250 | 0.85 | 2.400 | 1.80 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MDT3-160-36-C1 | 160 (88) | 3000-3600 | 4.0 | 400 | 1.20 | 2.300 | 2.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT3-165-22-F | 165 (85) | 2000-2200 | 4.7 | 160 | 0.80 | 1.350 | 1.50 | 500 | 125 | 0.1800 | 0.35 | F 94x34x30 |
| MDT3-200-28-C1 | 200 (93) | 2600-2800 | 5.5 | 250 | 0.90 | 1.100 | 2.00 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT3-201-18-F | 201 (85) | 1000-1800 | 6.0 | 125 | 0.80 | 0.970 | 1.40 | 500 | 130 | 0.1800 | 0.35 | F 94x34x30 |
| MDT3-240-65-A2 | 240 (85) | 4600-6500 | 4.0 | 630 | 1.10 | 2.500 | 2.10 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT3-250-24-C1 | 250 (91) | 2000-2400 | 7.6 | 200 | 0.80 | 0.700 | 1.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT3-260-44-A2 | 260 (85) | 3800-4400 | 5.0 | 500 | 1.40 | 1.300 | 2.30 | 628 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT3-320-18-C1 | 320 (90) | 1000-1800 | 8.5 | 160 | 0.75 | 0.500 | 1.40 | 785 | 130 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT3-320-36-A2 | 320 (85) | 3000-3600 | 5.5 | 320 | 1.15 | 0.800 | 2.20 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT3-400-28-A2 | 400 (82) | 2600-2800 | 9.0 | 250 | 1.00 | 0.650 | 1.80 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT3-400-44-D | 400 (88) | 3800-4400 | 14.0 | 500 | 1.20 | 0.650 | 2.70 | 2512 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3-430-24-A2 | 430 (85) | 2000-2400 | 12.0 | 250 | 1.00 | 1.410 | 1.55 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT3-500-36-D | 500 (85) | 3000-3600 | 18.0 | 400 | 1.10 | 0.400 | 1.85 | 1570 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3-540-18-A2 | 540 (85) | 1400-1800 | 15.5 | 250 | 0.85 | 0.320 | 1.50 | 1570 | 130 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT3-595-18-A2 | 595 (85) | 1400-1800 | 17.5 | 320 | 0.84 | 0.310 | 1.50 | 1570 | 135 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT3-630-28-D | 630 (80) | 2600-2800 | 21.0 | 320 | 0.95 | 0.300 | 1.40 | 1978 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3-650-12-A2 | 650 (85) | 1000-1200 | 14.0 | 160 | 0.85 | 0.280 | 1.40 | 1978 | 140 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT3-740-24-D | 740 (77) | 2000-2400 | 24.5 | 320 | 0.90 | 0.210 | 1.55 | 3140 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3-800-18-D | 800 (78) | 1400-1800 | 28.0 | 250 | 0.85 | 0.230 | 1.45 | 2512 | 130 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3-1000-12-D | 1000 (77) | 1000-1200 | 32.0 | 200 | 0.90 | 0.150 | 1.25 | 3140 | 140 | 0.0500 | 4.1 | D 150x77x84 |
| MDT3-1250-8-D | 1250 (77) | 100-800 | 34.0 | 160 | 0.80 | 0.120 | 1.20 | 3925 | 150 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4 | ||||||||||||
| MTD4-115-36-F | 115 (85) | 3000-3600 | 2.5 | 400 | 0.95 | 3.000 | 2.45 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MTD4-130-28-F | 130 (85) | 2400-2800 | 3.4 | 250 | 0.85 | 2.400 | 1.80 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MTD4-160-36-C1 | 160 (88) | 3000-3600 | 4.0 | 400 | 1.20 | 2.300 | 2.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD4-165-22-F | 165 (85) | 2000-2200 | 4.7 | 160 | 0.80 | 1.350 | 1.50 | 500 | 125 | 0.1800 | 0.35 | F 94x34x30 |
| MTD4-200-28-C1 | 200 (93) | 2600-2800 | 5.5 | 250 | 0.90 | 1.100 | 2.00 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD4-201-18-F | 201 (85) | 1000-1800 | 6.0 | 125 | 0.80 | 0.970 | 1.40 | 500 | 130 | 0.1800 | 0.35 | F 94x34x30 |
| MTD4-240-65-A2 | 240 (85) | 4600-6500 | 4.0 | 630 | 1.10 | 2.500 | 2.10 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD4-250-24-C1 | 250 (91) | 2000-2400 | 7.6 | 200 | 0.80 | 0.700 | 1.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD4-260-44-A2 | 260 (85) | 3800-4400 | 5.0 | 500 | 1.40 | 1.300 | 2.30 | 628 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD4-320-18-C1 | 320 (90) | 1000-1800 | 8.5 | 160 | 0.75 | 0.500 | 1.40 | 785 | 130 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD4-320-36-A2 | 320 (85) | 3000-3600 | 5.5 | 320 | 1.15 | 0.800 | 2.20 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD4-400-28-A2 | 400 (82) | 2600-2800 | 9.0 | 250 | 1.00 | 0.650 | 1.80 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD4-400-44-D | 400 (88) | 3800-4400 | 14.0 | 500 | 1.20 | 0.650 | 2.70 | 2512 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4-430-24-A2 | 430 (85) | 2000-2400 | 12.0 | 250 | 1.00 | 1.410 | 1.55 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD4-500-36-D | 500 (85) | 3000-3600 | 18.0 | 400 | 1.10 | 0.400 | 1.85 | 1570 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4-540-18-A2 | 540 (85) | 1400-1800 | 15.5 | 250 | 0.85 | 0.320 | 1.50 | 1570 | 130 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD4-595-18-A2 | 595 (85) | 1400-1800 | 17.5 | 320 | 0.84 | 0.310 | 1.50 | 1570 | 135 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD4-630-28-D | 630 (80) | 2600-2800 | 21.0 | 320 | 0.95 | 0.300 | 1.40 | 1978 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4-650-12-A2 | 650 (85) | 1000-1200 | 14.0 | 160 | 0.85 | 0.280 | 1.40 | 1978 | 140 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD4-740-24-D | 740 (77) | 2000-2400 | 24.5 | 320 | 0.90 | 0.210 | 1.55 | 3140 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4-800-18-D | 800 (78) | 1400-1800 | 28.0 | 250 | 0.85 | 0.230 | 1.45 | 2512 | 130 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4-1000-12-D | 1000 (77) | 1000-1200 | 32.0 | 200 | 0.90 | 0.150 | 1.25 | 3140 | 140 | 0.0500 | 4.1 | D 150x77x84 |
| MTD4-1250-8-D | 1250 (77) | 100-800 | 34.0 | 160 | 0.80 | 0.120 | 1.20 | 3925 | 150 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4 | ||||||||||||
| MDT4-115-36-F | 115 (85) | 3000-3600 | 2.5 | 400 | 0.95 | 3.000 | 2.45 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MDT4-130-28-F | 130 (85) | 2400-2800 | 3.4 | 250 | 0.85 | 2.400 | 1.80 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MDT4-160-36-C1 | 160 (88) | 3000-3600 | 4.0 | 400 | 1.20 | 2.300 | 2.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT4-165-22-F | 165 (85) | 2000-2200 | 4.7 | 160 | 0.80 | 1.350 | 1.50 | 500 | 125 | 0.1800 | 0.35 | F 94x34x30 |
| MDT4-200-28-C1 | 200 (93) | 2600-2800 | 5.5 | 250 | 0.90 | 1.100 | 2.00 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT4-201-18-F | 201 (85) | 1000-1800 | 6.0 | 125 | 0.80 | 0.970 | 1.40 | 500 | 130 | 0.1800 | 0.35 | F 94x34x30 |
| MDT4-240-65-A2 | 240 (85) | 4600-6500 | 4.0 | 630 | 1.10 | 2.500 | 2.10 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT4-250-24-C1 | 250 (91) | 2000-2400 | 7.6 | 200 | 0.80 | 0.700 | 1.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT4-260-44-A2 | 260 (85) | 3800-4400 | 5.0 | 500 | 1.40 | 1.300 | 2.30 | 628 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT4-320-18-C1 | 320 (90) | 1000-1800 | 8.5 | 160 | 0.75 | 0.500 | 1.40 | 785 | 130 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT4-320-36-A2 | 320 (85) | 3000-3600 | 5.5 | 320 | 1.15 | 0.800 | 2.20 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT4-400-28-A2 | 400 (82) | 2600-2800 | 9.0 | 250 | 1.00 | 0.650 | 1.80 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT4-400-44-D | 400 (88) | 3800-4400 | 14.0 | 500 | 1.20 | 0.650 | 2.70 | 2512 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4-430-24-A2 | 430 (85) | 2000-2400 | 12.0 | 250 | 1.00 | 1.410 | 1.55 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT4-500-36-D | 500 (85) | 3000-3600 | 18.0 | 400 | 1.10 | 0.400 | 1.85 | 1570 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4-540-18-A2 | 540 (85) | 1400-1800 | 15.5 | 250 | 0.85 | 0.320 | 1.50 | 1570 | 130 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT4-595-18-A2 | 595 (85) | 1400-1800 | 17.5 | 320 | 0.84 | 0.310 | 1.50 | 1570 | 135 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT4-630-28-D | 630 (80) | 2600-2800 | 21.0 | 320 | 0.95 | 0.300 | 1.40 | 1978 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4-650-12-A2 | 650 (85) | 1000-1200 | 14.0 | 160 | 0.85 | 0.280 | 1.40 | 1978 | 140 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT4-740-24-D | 740 (77) | 2000-2400 | 24.5 | 320 | 0.90 | 0.210 | 1.55 | 3140 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4-800-18-D | 800 (78) | 1400-1800 | 28.0 | 250 | 0.85 | 0.230 | 1.45 | 2512 | 130 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4-1000-12-D | 1000 (77) | 1000-1200 | 32.0 | 200 | 0.90 | 0.150 | 1.25 | 3140 | 140 | 0.0500 | 4.1 | D 150x77x84 |
| MDT4-1250-8-D | 1250 (77) | 100-800 | 34.0 | 160 | 0.80 | 0.120 | 1.20 | 3925 | 150 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5 | ||||||||||||
| MTD5-115-36-F | 115 (85) | 3000-3600 | 2.5 | 400 | 0.95 | 3.000 | 2.45 | 500 | 125 | 0.1900 | 0.35 | F 94x34x30 |
| MTD5-160-36-C1 | 160 (88) | 3000-3600 | 4.0 | 400 | 1.20 | 2.300 | 2.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD5-200-28-C1 | 200 (93) | 2600-2800 | 5.5 | 250 | 0.90 | 1.100 | 2.00 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD5-240-65-A2 | 240 (85) | 4600-6500 | 4.0 | 630 | 1.10 | 2.500 | 2.10 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD5-250-24-C1 | 250 (91) | 2000-2400 | 7.6 | 200 | 0.80 | 0.700 | 1.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD5-260-44-A2 | 260 (85) | 3800-4400 | 5.0 | 500 | 1.40 | 1.300 | 2.30 | 628 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD5-320-18-C1 | 320 (90) | 1000-1800 | 8.5 | 160 | 0.75 | 0.500 | 1.40 | 785 | 130 | 0.1100 | 0.86 | C1 92x52x50 |
| MTD5-320-36-A2 | 320 (85) | 3000-3600 | 5.5 | 320 | 1.15 | 0.800 | 2.20 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MTD5-400-28-A2 | 400 (82) | 2600-2800 | 9.0 | 250 | 1.00 | 0.650 | 1.80 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD5-400-44-D | 400 (88) | 3800-4400 | 14.0 | 500 | 1.20 | 0.650 | 2.70 | 2512 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5-430-24-A2 | 430 (85) | 2000-2400 | 12.0 | 250 | 1.00 | 1.410 | 1.55 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD5-500-36-D | 500 (85) | 3000-3600 | 18.0 | 400 | 1.10 | 0.400 | 1.85 | 1570 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5-540-18-A2 | 540 (85) | 1400-1800 | 15.5 | 250 | 0.85 | 0.320 | 1.50 | 1570 | 130 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD5-595-18-A2 | 595 (85) | 1400-1800 | 17.5 | 320 | 0.84 | 0.310 | 1.50 | 1570 | 135 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD5-630-28-D | 630 (80) | 2600-2800 | 21.0 | 320 | 0.95 | 0.300 | 1.40 | 1978 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5-650-12-A2 | 650 (85) | 1000-1200 | 14.0 | 160 | 0.85 | 0.280 | 1.40 | 1978 | 140 | 0.0650 | 1.5 | A2 124x60x52 |
| MTD5-740-24-D | 740 (77) | 2000-2400 | 24.5 | 320 | 0.90 | 0.210 | 1.55 | 3140 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5-800-18-D | 800 (78) | 1400-1800 | 28.0 | 250 | 0.85 | 0.230 | 1.45 | 2512 | 130 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5-1000-12-D | 1000 (77) | 1000-1200 | 32.0 | 200 | 0.90 | 0.150 | 1.25 | 3140 | 140 | 0.0500 | 4.1 | D 150x77x84 |
| MTD5-1250-8-D | 1250 (77) | 100-800 | 34.0 | 160 | 0.80 | 0.120 | 1.20 | 3925 | 150 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5 | ||||||||||||
| MDT5-160-36-C1 | 160 (88) | 3000-3600 | 4.0 | 400 | 1.20 | 2.300 | 2.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT5-200-28-C1 | 200 (93) | 2600-2800 | 5.5 | 250 | 0.90 | 1.100 | 2.00 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT5-240-65-A2 | 240 (85) | 4600-6500 | 4.0 | 630 | 1.10 | 2.500 | 2.10 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT5-250-24-C1 | 250 (91) | 2000-2400 | 7.6 | 200 | 0.80 | 0.700 | 1.50 | 785 | 125 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT5-260-44-A2 | 260 (85) | 3800-4400 | 5.0 | 500 | 1.40 | 1.300 | 2.30 | 628 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT5-320-18-C1 | 320 (90) | 1000-1800 | 8.5 | 160 | 0.75 | 0.500 | 1.40 | 785 | 130 | 0.1100 | 0.86 | C1 92x52x50 |
| MDT5-320-36-A2 | 320 (85) | 3000-3600 | 5.5 | 320 | 1.15 | 0.800 | 2.20 | 785 | 125 | 0.0680 | 1.5 | A2 124x60x52 |
| MDT5-400-28-A2 | 400 (82) | 2600-2800 | 9.0 | 250 | 1.00 | 0.650 | 1.80 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT5-400-44-D | 400 (88) | 3800-4400 | 14.0 | 500 | 1.20 | 0.650 | 2.70 | 2512 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5-430-24-A2 | 430 (85) | 2000-2400 | 12.0 | 250 | 1.00 | 1.410 | 1.55 | 1256 | 125 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT5-500-36-D | 500 (85) | 3000-3600 | 18.0 | 400 | 1.10 | 0.400 | 1.85 | 1570 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5-540-18-A2 | 540 (85) | 1400-1800 | 15.5 | 250 | 0.85 | 0.320 | 1.50 | 1570 | 130 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT5-595-18-A2 | 595 (85) | 1400-1800 | 17.5 | 320 | 0.84 | 0.310 | 1.50 | 1570 | 135 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT5-630-28-D | 630 (80) | 2600-2800 | 21.0 | 320 | 0.95 | 0.300 | 1.40 | 1978 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5-650-12-A2 | 650 (85) | 1000-1200 | 14.0 | 160 | 0.85 | 0.280 | 1.40 | 1978 | 140 | 0.0650 | 1.5 | A2 124x60x52 |
| MDT5-740-24-D | 740 (77) | 2000-2400 | 24.5 | 320 | 0.90 | 0.210 | 1.55 | 3140 | 125 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5-800-18-D | 800 (78) | 1400-1800 | 28.0 | 250 | 0.85 | 0.230 | 1.45 | 2512 | 130 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5-1000-12-D | 1000 (77) | 1000-1200 | 32.0 | 200 | 0.90 | 0.150 | 1.25 | 3140 | 140 | 0.0500 | 4.1 | D 150x77x84 |
| MDT5-1250-8-D | 1250 (77) | 100-800 | 34.0 | 160 | 0.80 | 0.120 | 1.20 | 3925 | 150 | 0.0500 | 4.1 | D 150x77x84 |
