Inductive proximity sensor LMF37
Home Products Proximity Photoelectric SensorInductive proximity sensor (Rectangular type)Inductive proximity sensor LMF37
Product Details
Inductive proximity sensor LMF37
Model NO. | Detection distance | Working voltage | Output | Flush | |
Form | State | ||||
LMF37-3015NA | 15mm | DC6-36V | NPN | NO | Flush |
LMF37-3015NB | 15mm | DC6-36V | NPN | NC | Flush |
LMF37-3015NC | 15mm | DC6-36V | NPN | NO NC | Flush |
LMF37-3015PA | 15mm | DC6-36V | PNP | NO | Flush |
LMF37-3015PB | 15mm | DC6-36V | PNP | NC | Flush |
LMF37-3015PC | 15mm | DC6-36V | PNP | NO NC | Flush |
LMF37-3015LA | 15mm | DC6-36V | Two wire system | NO | Flush |
LMF37 -3015LB | 15mm | DC6-36V | Two wire system | NC | Flush |
LMF37 -2015A | 15mm | AC90-250V | SCR Control label silicon | NO | Flush |
LMF37-2015B | 15mm | AC90-250V | SCR Control label silicon | NC | Flush |
LMF37 -2015C | 15mm | AC90-250V | SCR Control label silicon | NO NC | Flush |
LM37-3020NA | 20mm | DC6-36V | NPN | NO | Non-flush |
LMF37-3020NB | 20mm | DC6-36V | NPN | NC | Non-flush |
LMF37-3020NC | 20mm | DC6-36V | NPN | NO NC | Non-flush |
LMF37-3020PA | 20mm | DC6-36V | PNP | NO | Non-flush |
LMF37-3020PB | 20mm | DC6-36V | PNP | NC | Non-flush |
LMF37-3020PC | 20mm | DC6-36V | PNP | NO NC | Non-flush |
LMF37-3020LA | 20mm | DC6-36V | Two wire system | NO | Non-flush |
LMF37 -3020LB | 20mm | DC6-36V | Two wire system | NC | Non-flush |
LMF37 -2020A | 20mm | AC90-250V | SCR Control label silicon | NO | Non-flush |
LMF37-2020B | 20mm | AC90-250V | SCR Control label silicon | NC | Non-flush |
LMF37 -2020C | 20mm | AC90-250V | SCR Control label silicon | NO NC | Non-flush |
