Inductance proximity switch LMF50
Home Products Proximity Photoelectric SensorInductive proximity sensor (Rectangular type)Inductance proximity switch LMF50
Product Details
Inductance proximity switch LMF50
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LMF50-3020NA | 20mm | DC6-36V | NPN | NO | Non-flush |
| LMF50-3020NB | 20mm | DC6-36V | NPN | NC | Non-flush |
| LMF50-3020NC | 20mm | DC6-36V | NPN | NO NC | Non-flush |
| LMF50-3020PA | 20mm | DC6-36V | PNP | NO | Non-flush |
| LMF50-3020PB | 20mm | DC6-36V | PNP | NC | Non-flush |
| LMF50-3020PC | 20mm | DC6-36V | PNP | NO NC | Non-flush |
| LMF50 -2020A | 20mm | AC90-250V | SCR Control label silicon | NO | Non-flush |
| LMF50-2020B | 20mm | AC90-250V | SCR Control label silicon | NC | Non-flush |
| LMF50 -2020C | 20mm | AC90-250V | SCR Control label silicon | NO NC | Non-flush |
