DC coil magnetic contactors (LP1-D 4 pole)
Home Products Motor ProtectionElectrical AC ContactorDC coil magnetic contactors (LP1-D 4 pole)
Product Details
DC coil magnetic contactors (LP1-D 4 pole)
| Standard power ratings of 3-phase motors 50/60 Hz in category AC-3 | Rated operational current in AC-3 up to 440V (A) | Rated operational current in AC-1 up to 440V (A) | Rated noncondutive voltage (V) | Instantaneous auxi.contacts | Reference | ||||||
| 220V 230V (kW) | 380V 400V (kW) | 415V (kW) | 440V (kW) | 500V (kW) | 660V 690V (kW) | NO | NC | ||||
| 2.2 | 4 | 4 | 4 | 5.5 | 5.5 | 9 | 25 | 690 | 4 | - | GLP1-D09004 |
| 2 | 2 | GLP1-D09008 | |||||||||
| 3 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 12 | 25 | 690 | 4 | - | GLP1-D12004 |
| 2 | 2 | GLP1-D12008 | |||||||||
| 5.5 | 11 | 11 | 11 | 15 | 15 | 25 | 40 | 690 | 4 | - | GLP1-D25004 |
| 2 | 2 | GLP1-D25008 | |||||||||
| 11 | 18.5 | 22 | 22 | 30 | 30 | 40 | 60 | 690 | 4 | - | GLP1-D40004 |
| 2 | 2 | GLP1-D40008 | |||||||||
| 15 | 22 | 30 | 30 | 33 | 33 | 50 | 80 | 690 | 4 | - | GLP1-D50004 |
| 2 | 2 | GLP1-D50008 | |||||||||
| 18.5 | 30 | 37 | 37 | 37 | 37 | 65 | 80 | 690 | 4 | - | GLP1-D65004 |
| 2 | 2 | GLP1-D65008 | |||||||||
| 22 | 37 | 45 | 45 | 45 | 45 | 80 | 125 | 690 | 4 | - | GLP1-D80004 |
| 2 | 2 | GLP1-D80008 | |||||||||
| 25 | 45 | 45 | 45 | 45 | 45 | 95 | 125 | 690 | 4 | - | GLP1-D95004 |
| 2 | 2 | GLP1-D95008 | |||||||||
