DZ1070N22K Single Diode Module High Performance
DZ1070N22K Single Diode Module High Performance
DZ1070N22K Single Diode Module Press contact type
DZ1070N22K Single Diode Module 1100A 2200V
Product details

Single Rectifier Diode Modules Infineon Replacement

Features

  • Pressure contact technology for high reliability
  • Industial standard package
  • Electrically insulated baseplate
  • Advanced medium power technology

Typical Applications

  • Rectifier for Drives Applications
  • Rectifiers for UPS
  • Battery chargers
Part numbers list
Type IF(AV)M
 VRRM
VDRM		 IFSM I²t VT0 rT Tvj max Rth((j-c) W Package, Dimensions L×B×H
A V A kA²·s V mΩ ℃ K/W kg mm
ND89N16K 89 1600 2400 28.8 0.75 2.3 150 0.45 160 DP20
92x20x30
ND89N12K 89 1200 2400 28.8 0.75 2.3 150 0.45 160 DP20
92x20x30
ND104N18K 104 1800 2500 31.25 0.7 2.1 150 0.39 160 DP20
92x20x30
ND104N16K 104 1600 2500 31.25 0.7 2.1 150 0.39 160 DP20
92x20x30
ND104N12K 104 1200 2500 31.25 0.7 2.1 150 0.39 160 DP20
92x20x30
ND171N18K 170 1800 5600 157 0.75 0.8 150 0.26 310 DP34
94x34x30
ND171N16K 170 1600 5600 157 0.75 0.8 150 0.26 310 DP34
94x34x30
ND261N26K 260 2600 8300 344 0.7 0.68 150 0.17 700 DP50ND
92x50x52
ND260N16K 260 1600 8300 344 0.7 0.68 150 0.17 700 DP50ND
92x50x52
ND260N14K 260 1400 8300 344 0.7 0.68 150 0.17 700 DP50ND
92x50x52
DZ435N40K 435 4000 12000 720 0.84 0.6 150 0.078 900 DP50.1
101x50x52
DZ435N36K 435 3600 12000 720 0.84 0.6 150 0.078 900 DP50.1
101x50x52
DZ540N26K 540 2600 14000 980 0.78 0.31 150 0.078 900 DP50.1
101x50x52
DZ540N22K 540 2200 14000 980 0.78 0.31 150 0.078 900 DP50.1
101x50x52
DZ600N18K 600 1800 19000 1805 0.75 0.22 150 0.078 900 DP50.1
101x50x52
DZ600N16K 600 1600 19000 1805 0.75 0.22 150 0.078 900 DP50.1
101x50x52
DZ600N12K 600 1200 19000 1805 0.75 0.22 150 0.078 900 DP50.1
101x50x52
DZ950N44K 950 4400 29000 4205 0.85 0.28 150 0.042 2750 DP70
104x70x90
DZ950N36K 950 3600 29000 4205 0.85 0.28 150 0.042 2750 DP70
104x70x90
DZ1070N28K 1070 2800 35000 6125 0.8 0.17 160 0.045 2750 DP70
104x70x90
DZ1070N26K 1070 2600 35000 6125 0.8 0.17 160 0.045 2750 DP70
104x70x90
DZ1100N22K 1100 2200 40000 8000 0.75 0.073 150 0.048 1950 DP70A
104x70x90
DZ1070N22K 1100 2200 35000 6125 0.75 0.073 150 0.045 1950 DP70A
104x70x90
DZ1070N18K 1100 1800 35000 6125 0.75 0.073 150 0.045 1950 DP70A
104x70x90
