SKKE120F17 Fast Diode Module

Features
• CAL (controlled axial lifetime) chip technology
• Heat transfer through ceramic isolated metal baseplate
• Very short recovery times
• Soft recovery
• Low switching losses
• UL recognized

Typical Applications
• Self-commutated inverters
• DC choppers
• AC motor speed control
• inductive heating
• Uninterruptible power supplies
• Electronic welders
• General power switching applications
• snubber and free wheeling circuits

SKKE120F17 FRED Module
