Product Details

4RCBE single modular rcbo

Greegoo’s new DIN mounted, 30mA combination RCD/MCBs are available as single pole devices to save valuable switchboard space.Just 18mm wide and available in 6 current ratings, these combination devices have a short circuit interrupting capacity of 3kA, rated at 240V, 30/10mA, with a thermal/overload protection C - Curve.

Applications
- Suitable for residential, commercial and industrial applications.
- Ideal for retrofit installations where pole space is a problem.
- Small width allows a greater number of RCD/MCBs to be installed in the one enclosure.
- 1 Module width is ideal for new installations where space is limited.
- Combination Head Screws for quick and easy termination.
- Lift-up terminals for safer ‘no hot spot’ termination. All wires are locked in.

Model Number		4RCBE
Tripping Mode		ELECTRONIC TYPE
Pole No.	Pole	1P
Standard Conformity		IEC 61009-1
Tripping Characteristic		B/C
Rated Current (In)	A	6, 10, 16, 20, 25, 32
Sensitivity (I △ n)	mA	30, 100
Residual Tripping Current Range		0.5I △ n~1I △ n
Rated Voltage (Un)	Vac	230/240
Rated Insulation Voltage (Ui)	V	660
Rated Frequency	Hz	50/60
Type		AC/A
Tripping Time	S	≤0.1
Shortcircuit Withstand Capacity	kA	3
Ambient Temperature	oC	-25 to 40
Electrical Mechanical Operation	cycles	4000
Mounting		Din Rail (35 * 7.5) mm
Degree of Protection		IP 20
Terminal Capacity (max)	mm2	10~16
Connection Terminals		Screw Terminals 2.0Nm
Certificate		CE

Model Selection

Rated Current (A)	30mA		100mA
6A	4RCBE20630C	4RCBE20630B	4RCBE206100C	4RCBE206100B
10A	4RCBE21030C	4RCBE21030B	4RCBE210100C	4RCBE210100B
16A	4RCBE21630C	4RCBE21630B	4RCBE216100C	4RCBE216100B
20A	4RCBE22030C	4RCBE22030B	4RCBE220100C	4RCBE220100B
25A	4RCBE22530C	4RCBE22530B	4RCBE225100C	4RCBE225100B
32A	4RCBE23230C	4RCBE23230B	4RCBE232100C	4RCBE232100B
