DZ30LE RCBO Circuit Breakers

APPLICATION
DZ30LE-32(phase line neutral line leakage) series residual circuit breaker is suitable to the single phase residual circuit of 50/60Hz, rated voltage 230V, as the current leakage protection and protect the civil electrical circuit from over load and short circuit and it has the features of volume small, breaking capacity high. Null/live wire is cut at the same time, and even the wire is reverse connection, it still has current leakage protection.The product conforms to standards IEC1009.1.

TECHNICAL PARAMETER

Model	Rated Voltage(V)	Pole	Shell-level rated current(A)	Rated Current In(A)	Rated breaking residuaf current(mA)	Rated Not breaking residuaf current(mA)	Breaking time of rated residul current(s)	Breaking Capacity (A)	Breaking value of over-voltage(V)
DZ30LE-32	230	1P N	32A	6,10,16,20,25,32	30	15	≤0.1	3000	280V±5V

TRIPPING CHARACTERISTICS

Test current (A)	Rated Voltage(V)	Requested time	Result	Start station
1.13In	All	t≥1h	Don't trip	Cool
1.45In	All	t<1h	trip	Heat
2.55In	All	Is<t<60S	trip	Cool
5In	All	t≥0.1S	Don't trip	Cool
10In	All	t<0.1S	trip	Cool
