1200V IGBT Modules

Greegoo offers IGBT (insulated-gate bipolar transistor) modules in different topologies, current and voltage ratings. Starting from 15A to 1600A in voltage classes from 600V to 1700V, the IGBT modules are used in a variety of applications and feature key technologies such as sintering, spring or press-fit contacts for quick and easy assembly. Different topologies such as CIB (converter inverter brake), half-bridge, H-bridge, 6-pack and 3-level are available, covering almost every application field. Such as inverter welding machine; inverter power supply, frequency converter, UPS; electric vehicle; photovoltaic inverter, industrial servo service; switched reluctance motor, chopper speed regulation; induction heating, etc.


- 600/650V IGBT Module - 1200V IGBT Modules
- 1700V IGBT Modules


Type VCES IC  VCE(sat) E(on+off) Rth(J-C) Packages
Tc=25℃ Tc=80℃ Tj=25℃ Tj=125℃
(V) (A) (V) (mJ) (K/W)
G50SG120TE-F4 1200 50 1.9 12.50 0.3 F4
G75SG120TE-F4 1200 75 1.9 16.80 0.19 F4
G300SG120TE-G3 1200 300 1.9 36.00 0.12 G3
G400SG120TE-G3 1200 400 1.9 39.00 0.11 G3
G600SG120TE-G3 1200 600 1.9 64.80 0.08 G3
G50SG120TK-F4 1200 50 2.2 9.90 0.28 F4
G75SG120TK-F4 1200 75 2.2 12.90 0.16 F4
G300SG120TK-G3 1200 300 2.2 25.00 0.13 G3
G400SG120TK-G3 1200 400 2.2 30.00 0.10 G3
G600SG120TK-G3 1200 600 2.2 48.00 0.07 G3
G50HF120S-G1 1200 50 1.9 11.60 0.35 G1
G75HF120S-G1 1200 75 1.9 18.40 0.29 G1
G100HF120S-G1 1200 100 1.9 19.60 0.25 G1
G150HF120S-G2 1200 150 1.9 33.00 0.12 G2
G200HF120S-G2 1200 200 1.9 44.00 0.09 G2
G300HF120S-G2 1200 300 1.9 64.00 0.60 G2
G50HF120TE-G1 1200 50 1.9 12.50 0.28 G1
G75HF120TE-G1 1200 75 1.9 16.80 0.23 G1
G100HF120TE-G1 1200 100 1.9 18.40 0.19 G1
G150HF120TE-G2 1200 150 1.9 36.00 0.12 G2
G200HF120TE-G2 1200 200 1.9 39.00 0.11 G2
G300HF120TE-G2 1200 300 1.9 64.80 0.08 G2
G400HF120TE-G2 1200 400 1.9 85.00 0.51 G2
G50HF120TK-G1 1200 50 2.2 9.90 0.29 G1
G75HF120TK-G1 1200 75 2.2 12.90 0.23 G1
G100HF120TK-G1 1200 100 2.2 13.60 0.20 G1
G150HF120TK-G2 1200 150 2.2 25.00 0.13 G2
G200HF120TK-G2 1200 200 2.2 30.00 0.10 G2
G300HF120TK-G2 1200 300 2.2 48.00 0.07 G2
G400HF120TK-G2 1200 400 2.2 64.00 0.05 G2
G40HF120NU-M1 1200 40 3.1 8.10 0.38 M1
G50HF120NU-G1 1200 50 3.1 8.60 0.35 G1
G75HF120NU-G1 1200 75 3.1 9.20 0.30 G1
G100HF120NU-G1 1200 100 3.1 12.70 0.25 G1
G150HF120NU-G2 1200 150 3.1 19.00 0.12 G2
G200HF120NU-G2 1200 200 3.1 30.00 0.09 G2
G300HF120NU-G2 1200 300 3.1 51.00 0.06 G2
G50CU120S-G1 1200 50 1.9 11.60 0.35 G1
G75CU120S-G1 1200 75 1.9 18.40 0.29 G1
G100CU120S-G1 1200 100 1.9 19.60 0.25 G1
G150CU120S-G2 1200 150 1.9 33.00 0.12 G2
G200CU120S-G2 1200 200 1.9 44.00 0.09 G2
G300CU120S-G2 1200 300 1.9 64.00 0.60 G2
G50CU120TE-G1 1200 50 1.9 12.50 0.28 G1
G75CU120TE-G1 1200 75 1.9 16.80 0.23 G1
G100CU120TE-G1 1200 100 1.9 18.40 0.19 G1
G150CU120TE-G2 1200 150 1.9 36.00 0.12 G2
G200CU120TE-G2 1200 200 1.9 39.00 0.11 G2
G300CU120TE-G2 1200 300 1.9 64.80 0.08 G2
G400CU120TE-G2 1200 400 1.9 85.00 0.51 G2
G50CU120TK-G1 1200 50 2.2 9.90 0.29 G1
G75CU120TK-G1 1200 75 2.2 12.90 0.23 G1
G100CU120TK-G1 1200 100 2.2 13.60 0.20 G1
G150CU120TK-G2 1200 150 2.2 25.00 0.13 G2
G200CU120TK-G2 1200 200 2.2 30.00 0.10 G2
G300CU120TK-G2 1200 300 2.2 48.00 0.07 G2
G400CU120TK-G2 1200 400 2.2 64.00 0.05 G2
G40CU120NU-M1 1200 40 3.1 8.10 0.38 M1
G50CU120NU-G1 1200 50 3.1 8.60 0.35 G1
G75CU120NU-G1 1200 75 3.1 9.20 0.30 G1
G100CU120NU-G1 1200 100 3.1 12.70 0.25 G1
G150CU120NU-G2 1200 150 3.1 19.00 0.12 G2
G200CU120NU-G2 1200 200 3.1 30.00 0.09 G2
G300CU120NU-G2 1200 300 3.1 51.00 0.06 G2
G50CU120S-G1 1200 50 1.9 11.60 0.35 G1
G75CU120S-G1 1200 75 1.9 18.40 0.29 G1
G100CU120S-G1 1200 100 1.9 19.60 0.25 G1
G150CU120S-G2 1200 150 1.9 33.00 0.12 G2
G200CU120S-G2 1200 200 1.9 44.00 0.09 G2
G300CU120S-G2 1200 300 1.9 64.00 0.60 G2
G50CU120TE-G1 1200 50 1.9 12.50 0.28 G1
G75CU120TE-G1 1200 75 1.9 16.80 0.23 G1
G100CU120TE-G1 1200 100 1.9 18.40 0.19 G1
G150CU120TE-G2 1200 150 1.9 36.00 0.12 G2
G200CU120TE-G2 1200 200 1.9 39.00 0.11 G2
G300CU120TE-G2 1200 300 1.9 64.80 0.08 G2
G400CU120TE-G2 1200 400 1.9 85.00 0.51 G2
G50CU120TK-G1 1200 50 2.2 9.90 0.29 G1
G75CU120TK-G1 1200 75 2.2 12.90 0.23 G1
G100CU120TK-G1 1200 100 2.2 13.60 0.20 G1
G150CU120TK-G2 1200 150 2.2 25.00 0.13 G2
G200CU120TK-G2 1200 200 2.2 30.00 0.10 G2
G300CU120TK-G2 1200 300 2.2 48.00 0.07 G2
G400CU120TK-G2 1200 400 2.2 64.00 0.05 G2
G40CU120NU-M1 1200 40 3.1 8.10 0.38 M1
G50CU120NU-G1 1200 50 3.1 8.60 0.35 G1
G75CU120NU-G1 1200 75 3.1 9.20 0.30 G1
G100CU120NU-G1 1200 100 3.1 12.70 0.25 G1
G150CU120NU-G2 1200 150 3.1 19.00 0.12 G2
G200CU120NU-G2 1200 200 3.1 30.00 0.09 G2
G300CU120NU-G2 1200 300 3.1 51.00 0.06 G2
G300HF120S-G8 1200 300 1.9 64.00 0.05 G8
G450HF120S-G8 1200 450 1.9 96.00 0.04 G8
G300HF120TE-G8 1200 300 1.9 48.00 0.06 G8
G450HF120TE-G8 1200 450 1.9 98.00 0.05 G8
G600HF120TE-G8 1200 600 1.9 142.00 0.03 G8
G300HF120TK-G8 1200 300 2.2 45.00 0.06 G8
G450HF120TK-G8 1200 450 2.2 92.00 0.05 G8
G600HF120TK-G8 1200 600 2.2 136.00 0.03 G8
G25FF120TK-E1 1200 25 2.2 5.46 0.72 E1-FF
G35FF120TK-E1 1200 35 2.2 7.90 0.45 E1-FF
G50FF120TK-E2 1200 50 2.2 11.60 0.36 E2-FF
G75FF120TK-E2 1200 75 2.2 18.40 0.28 E2-FF
G15PI60TK-E1 1200 15 2.2 2.95 0.85 E1-PI
G25PI60TK-E2 1200 25 2.2 5.46 0.72 E2-PI
G30PI60TK-E2 1200 30 2.2 7.90 0.45 E2-PI
G75FF120TE-G5 1200 75 1.9 12.80 0.29 G5-FF
G100FF120TE-G5 1200 100 1.9 13.60 0.23 G5-FF
G150FF120TE-G5 1200 150 1.9 24.60 0.18 G5-FF
G25FF120TK-G4 1200 25 2.2 5.46 0.60 G4-FF
G35FF120TK-G4 1200 35 2.2 7.80 0.45 G4-FF
G50FF120TK-G4 1200 50 2.2 11.50 0.35 G4-FF
G75FF120TK-G5 1200 75 2.2 18.40 0.25 G5-FF
G100FF120TK-G5 1200 100 2.2 19.60 0.18 G5-FF
G50PI120TE-G5 1200 50 1.9 10.00 0.42 G5-PI
G75PI120TE-G5 1200 75 1.9 13.00 0.29 G5-PI
G100PI120TE-G5 1200 100 1.9 13.60 0.22 G5-PI
G15PI120TK-G4 1200 15 2.2 3.00 0.80 G4-PI
G25PI120TK-G4 1200 25 2.2 5.50 0.60 G4-PI
G40PI120TK-G4 1200 40 2.2 8.40 0.42 G4-PI
G50PI120TK-G5 1200 50 2.2 11.50 0.35 G5-PI
G75PI120TK-G5 1200 75 2.2 18.50 0.25 G5-PI
G150CH120S-G7 1200 150 1.9 28.5 0.11 G7
G200CH120S-G7 1200 200 1.9 32 0.08 G7
G150CH120TE-G7 1200 150 1.9 29 0.12 G7
G200CH120TE-G7 1200 200 1.9 32.8 0.09 G7
G300CH120TE-G7 1200 300 1.9 66 0.07 G7
G300CH120TE-G8 1200 300 1.9 66 0.06 G8
G400CH120TE-G8 1200 400 1.9 98 0.05 G8
G450CH120TE-A1 1200 450 1.9 93 0.04 A1
G600CH120TE-A1 1200 600 1.9 138 0.03 A1
G150TL120TE-G7 1200 150 1.9 25.00 0.13 G7
G200TL120TE-G7 1200 200 1.9 30.00 0.10 G7
G300TL120TE-G7 1200 300 1.9 48.00 0.07 G7
G150TL120TK-G7 1200 150 2.2 33.00 0.12 G7
G200TL120TK-G7 1200 200 2.2 44.00 0.09 G7
G300TL120TK-G7 1200 300 2.2 64.00 0.07 G7
