Single phase bridge rectifier KBPC3510
Feature
■ International standard package
■ Low forward voltage drop
■ Isolation voltage 2000V Application Maximum value
Electrical characteristics
■ DC power suppliers for apparatus device
■ Input rectifying power supply for PWM converters
■ Inverter welders
| Type | V RRM | I O | @T | I FSM | I R | V FM | @I FM |
| V | A | ℃ | A | uA | V | A | |
| KBPC1002 | 200 | 10 | 55 | 200 | 10 | 1.1 | 5 |
| KBPC1006 | 600 | 10 | 55 | 200 | 10 | 1.1 | 5 |
| KBPC1010 | 1000 | 10 | 55 | 200 | 10 | 1.1 | 5 |
| KBPC1502 | 200 | 15 | 55 | 300 | 10 | 1.2 | 7.5 |
| KBPC1506 | 600 | 15 | 55 | 300 | 10 | 1.2 | 7.5 |
| KBPC1510 | 1000 | 15 | 55 | 300 | 10 | 1.2 | 7.5 |
| KBPC2502 | 200 | 25 | 55 | 300 | 10 | 1.2 | 12.5 |
| KBPC2506 | 600 | 25 | 55 | 300 | 10 | 1.2 | 12.5 |
| KBPC2510 | 1000 | 25 | 55 | 300 | 10 | 1.2 | 12.5 |
| KBPC3502 | 200 | 35 | 55 | 400 | 10 | 1.2 | 17.5 |
| KBPC3506 | 600 | 35 | 55 | 400 | 10 | 1.2 | 17.5 |
| KBPC3510 | 1000 | 35 | 55 | 400 | 10 | 1.2 | 17.5 |
| KPBC3512 | 1200 | 35 | 55 | 400 | 10 | 1.2 | 17.5 |
| KPBC3516 | 1600 | 35 | 55 | 400 | 10 | 1.2 | 17.5 |
