Phase Control Thyristor ST180/230/280S
| Type | IT(AV) | VTM/ITM | ITRMS | VRRM | IRRM | IGT | IH | IL | dv/dt | Rjc | M2 | Wt | Out | |
| THS55℃ | 25℃ | |||||||||||||
| A | V | A | A | V | mA | mA | mA | mA | mA | ℃/W | N/m | kg | ||
| ST180S | 200 | 1.75 | 600 | 320 | 200-1800 | ≤20 | 50-200 | ≤400 | ≤600 | ≥800 | ≤0.4 | ≤25 | 0.28 | TO-93 |
| ST230S | 250 | 1.75 | 750 | 400 | 200-1800 | ≤20 | 50-200 | ≤400 | ≤600 | ≥800 | ≤0.2 | ≤25 | 0.28 | |
| ST280S | 280 | 1.7 | 840 | 450 | 200-1800 | ≤25 | 50-200 | ≤400 | ≤600 | ≥800 | ≤0.15 | ≤25 | 0.28 | |
