Inductive sensor LM12 straight connector type
Home Products Proximity Photoelectric SensorInductive proximity sensor (Cylinder type)Inductive sensor LM12 straight connector type
Product Details
Inductive sensor LM12 straight connector type
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LM12-3002NAT1 | 2mm | DC6-36V | NPN | NO | Flush |
| LM12-3002NBT1 | 2mm | DC6-36V | NPN | NC | Flush |
| LM12-3002NCT1 | 2mm | DC6-36V | NPN | NO NC | Flush |
| LM12-3002PAT1 | 2mm | DC6-36V | PNP | NO | Flush |
| LM12-3002PBT1 | 2mm | DC6-36V | PNP | NC | Flush |
| LM12-3002PCT1 | 2mm | DC6-36V | PNP | NO NC | Flush |
| LM12-3002LAT1 | 2mm | DC6-36V | Two wire system | NO | Flush |
| LM12-3002LBT1 | 2mm | DC6-36V | Two wire system | NC | Flush |
| LM12-2002AT1 | 2mm | AC90-250V | SCR Control label silicon | NO | Flush |
| LM12-2002BT1 | 2mm | AC90-250V | SCR Control label silicon | NC | Flush |
| LM12-3004NAT1 | 4mm | DC6-36V | NPN | NO | Non-flush |
| LM12-3004NBT1 | 4mm | DC6-36V | NPN | NC | Non-flush |
| LM12-3004NCT1 | 4mm | DC6-36V | NPN | NO NC | Non-flush |
| LM12-3004PAT1 | 4mm | DC6-36V | PNP | NO | Non-flush |
| LM12-3004PBT1 | 4mm | DC6-36V | PNP | NC | Non-flush |
| LM12-3004PCT1 | 4mm | DC6-36V | PNP | NO NC | Non-flush |
| LM12-3004LAT1 | 4mm | DC6-36V | Two wire system | NO | Non-flush |
| LM12-3004LBT1 | 4mm | DC6-36V | Two wire system | NC | Non-flush |
| LM12-2004AT1 | 4mm | AC90-250V | SCR Control label silicon | NO | Non-flush |
| LM12-2004BT1 | 4mm | AC90-250V | SCR Control label silicon | NC | Non-flush |
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
