G50 photoelectric sensors
| Model | Sensing Distrance | Operation voltage | Output | Response time | Sensing method | |
| Method | Mode | |||||
| G50-3A30NA | 30cm 50cm | DC10-30V | NPN | NO | <2mS | Diffuse type |
| G50-3A30NB | 30cm 50cm | DC10-30V | NPN | NC | <2mS | Diffuse type |
| G50-3A30NC | 30cm 50cm | DC10-30V | NPN | NO NC | <2mS | Diffuse type |
| G50-3A30PA | 30cm 50cm | DC10-30V | PNP | NO | <2mS | Diffuse type |
| G50-3A30PB | 30cm 50cm | DC10-30V | PNP | NC | <2mS | Diffuse type |
| G50-3A30PC | 30cm 50cm | DC10-30V | PNP | NO NC | <2mS | Diffuse type |
| G50-3B4NA | 4m | DC10-30V | NPN | NO | <2mS | Mirror reflex type |
| G50-3B4NB | 4m | DC10-30V | NPN | NC | <2mS | Mirror reflex type |
| G50-3B4NC | 4m | DC10-30V | NPN | NO NC | <2mS | Mirror reflex type |
| G50-3B4PA | 4m | DC10-30V | PNP | NO | <2mS | Mirror reflex type |
| G50-3B4PB | 4m | DC10-30V | PNP | NC | <2mS | Mirror reflex type |
| G50-3B4PC | 4m | DC10-30V | PNP | NO NC | <2mS | Mirror reflex type |
| G50-3C5NA | 5m | DC10-30V | NPN | NO | <2mS | Through beam |
| G50-3C5NB | 5m | DC10-30V | NPN | NC | <2mS | Through beam |
| G50-3C5NC | 5m | DC10-30V | NPN | NO NC | <2mS | Through beam |
| G50-3C5PA | 5m | DC10-30V | PNP | NO | <2mS | Through beam |
| G50-3C5PB | 5m | DC10-30V | PNP | NC | <2mS | Through beam |
| G50-3C5PC | 5m | DC10-30V | PNP | NO NC | <2mS | Through beam |
| G50-2C5LA | 5m | AC90-250V | SCR | NO | <2mS | Through beam |
