Dual solid state relays
Dual output solid state relays
GM series Solid State Relays are Dual AC relays,Triac or SCR Output. The Triac version of the zero switching relay is an inexpensive solution for resistive loads. The zero switching relay switches on when the AC sine voltage just crosses zero,and switches off when the current crosses zero. The SCR Output is Dual SCR Power Hybrid technology provides highly efficient thermal management for greatly increased cyclic life.
- Rated operational current 10 10 to 40 40 Amps.
- Rated operational voltage 240V
- Input Voltage Range 4 to 16 Vdc.
- 2500 Vrms Optical Isolation.(input/output)
- Both “Zero Voltage” & phase controllable “Random Switching” versions.
| Voltage | Control voltage | Rated operational current | |||
| 10Amp | 15Amp | 25Amp | 40Amp | ||
| 240 VAC “Z” | 4~16 Vdc | GM1024ZD1 | GM1524ZD1 | GM2524ZD1 | GM4024ZD1 |
| 240 VAC “R” | 4~16 Vdc | GM1024RD1 | GM1524RD1 | GM2524RD1 | GM4024RD1 |
| 440 VAC “Z” | 4~16 Vdc | GM1044ZD1 | GM1544ZD1 | GM2544ZD1 | GM4044ZD1 |
| 440 VAC “R” | 4-16 Vdc | GM1044RD1 | GM1544RD1 | GM2544RD1 | GM4044RD1 |
Need more information?
Contact us to request pricing, availability and customization options.
