Common Anode Dual Diode Modules

Series IF(AV)
(TC)		 VRRM  IFSM I²t  IRRM  VFM
IFM 		 V(TO)  rT  Rth(j-c)  Tjmax  W  Outline
A (°C) V  kA kA²·s mA V/A V mΩ °C/W °C g
MDA26-10 26 (100) 1000 0.65 2.1 8 1.65/80 0.8 6.8 1.3 150 115 92x20x30
MDA26-12 26 (100) 1200 0.65 2.1 8 1.65/80 0.8 6.8 1.3 150 115 92x20x30
MDA26-14 26 (100) 1900 0.65 2.1 8 1.65/80 0.8 6.8 1.3 150 115 92x20x30
MDA26-16 26 (100) 1600 0.65 2.1 8 1.65/80 0.8 6.8 1.3 150 115 92x20x30
MDA26-18 26 (100) 1800 0.65 2.1 8 1.65/80 0.8 6.8 1.3 150 115 92x20x30
MDA26-19 26 (100) 1900 0.65 2.1 8 1.53/80 0.85 5.94 1.3 150 115 92x20x30
MDA26-20 26 (100) 2000 0.65 2.1 8 1.53/80 0.85 5.94 1.3 150 115 92x20x30
MDA26-22 26 (100) 2200 0.65 2.1 8 1.53/80 0.85 5.94 1.3 150 115 92x20x30
MDA26-24 26 (100) 2400 0.65 2.1 8 1.53/80 0.85 5.94 1.3 150 115 92x20x30
MDA40-10 40 (100) 1000 1 5 8 1.55/120 0.8 5.57 0.9 150 115 92x20x30
MDA40-12 40 (100) 1200 1 5 8 1.55/120 0.8 5.57 0.9 150 115 92x20x30
MDA40-14 40 (100) 1400 1 5 8 1.55/120 0.8 5.57 0.9 150 115 92x20x30
MDA40-16 40 (100) 1600 1 5 8 1.55/120 0.8 5.57 0.9 150 115 92x20x30
MDA40-18 40 (100) 1800 1 5 8 1.55/120 0.8 5.57 0.9 150 115 92x20x30
MDA40-19 40 (100) 1900 1 5 8 1.59/120 0.85 4.5 0.9 150 115 92x20x30
MDA40-20 40 (100) 2000 1 5 8 1.59/120 0.85 4.5 0.9 150 115 92x20x30
MDA40-22 40 (100) 2200 1 5 8 1.59/120 0.85 4.5 0.9 150 115 92x20x30
MDA40-24 40 (100) 2400 1 5 8 1.59/120 0.85 4.5 0.9 150 115 92x20x30
MDA55-10 55 (100) 1000 1.3 8.45 8 1.45/170 0.8 3.47 0.7 150 115 92x20x30
MDA55-12 55 (100) 1200 1.3 8.45 8 1.45/170 0.8 3.47 0.7 150 115 92x20x30
MDA55-14 55 (100) 1400 1.3 8.45 8 1.45/170 0.8 3.76 0.7 150 115 92x20x30
MDA55-16 55 (100) 1600 1.3 8.45 8 1.45/170 0.8 3.76 0.7 150 115 92x20x30
MDA55-18 55 (100) 1800 1.3 8.45 8 1.45/170 0.8 3.76 0.7 150 115 92x20x30
MDA55-19 55 (100) 1900 1.3 8.45 8 1.55/170 0.85 3.76 0.68 150 115 92x20x30
MDA55-20 55 (100) 2000 1.3 8.45 8 1.55/170 0.85 3.76 0.68 150 115 92x20x30
MDA55-22 55 (100) 2200 1.3 8.45 8 1.55/170 0.85 3.76 0.68 150 115 92x20x30
MDA55-24 55 (100) 2400 1.3 8.45 8 1.55/170 0.85 3.76 0.68 150 115 92x20x30
MDA70-10 70 (100) 1000 1.8 16.2 8 1.40/210 0.8 2.5 0.57 150 115 92x20x30
MDA70-12 70 (100) 1200 1.8 16.2 8 1.40/210 0.8 2.5 0.57 150 115 92x20x30
MDA70-14 70 (100) 1400 1.8 16.2 8 1.40/210 0.8 2.73 0.57 150 115 92x20x30
MDA70-16 70 (100) 1600 1.8 16.2 8 1.40/210 0.8 2.73 0.57 150 115 92x20x30
MDA70-18 70 (100) 1800 1.8 16.2 8 1.40/210 0.8 2.73 0.57 150 115 92x20x30
MDA70-19 70 (100) 1900 1.8 16.2 8 1.50/210 0.85 2.73 0.55 150 115 92x20x30
MDA70-20 70 (100) 2000 1.8 16.2 8 1.50/210 0.85 2.73 0.55 150 115 92x20x30
MDA70-22 70 (100) 2200 1.8 16.2 8 1.50/210 0.85 2.73 0.55 150 115 92x20x30
MDA70-24 70 (100) 2400 1.8 16.2 8 1.50/210 0.85 2.73 0.55 150 115 92x20x30
MDA90-10 90 (100) 1000 2.3 26 8 1.33/270 0.8 1.7 0.47 150 115 92x20x30
MDA90-12 90 (100) 1200 2.3 26 8 1.33/270 0.8 1.7 0.47 150 115 92x20x30
MDA90-14 90 (100) 1400 2.3 26 8 1.33/270 0.8 1.7 0.47 150 115 92x20x30
MDA90-16 90 (100) 1600 2.3 26 8 1.33/270 0.8 1.7 0.47 150 115 92x20x30
MDA90-18 90 (100) 1800 2.3 26 8 1.33/270 0.8 1.7 0.47 150 115 92x20x30
MDA90-19 90 (100) 1900 2.3 26 8 1.43/270 0.85 1.88 0.45 150 115 92x20x30
MDA90-20 90 (100) 2000 2.3 26 8 1.43/270 0.85 1.88 0.45 150 115 92x20x30
MDA90-22 90 (100) 2200 2.3 26 8 1.43/270 0.85 1.88 0.45 150 115 92x20x30
MDA90-24 90 (100) 2400 2.3 26 8 1.43/270 0.85 1.88 0.45 150 115 92x20x30
MDA110-10 110 (100) 1000 2.6 33 8 1.45/330 0.8 1.74 0.35 150 115 92x20x30
MDA110-12 110 (100) 1200 2.6 33 8 1.45/330 0.8 1.74 1.35 150 115 92x20x30
MDA110-14 110 (100) 1400 2.6 33 8 1.45/330 0.8 1.88 1.35 150 115 92x20x30
MDA110-16 110 (100) 1600 2.6 33 8 1.45/330 0.8 1.88 1.35 150 115 92x20x30
MDA110-18 110 (100) 1800 2.6 33 8 1.45/330 0.8 1.88 1.35 150 115 92x20x30
MDA110-19 110 (100) 1900 2.6 33 8 1.55/330 0.85 1.88 0.33 150 115 92x20x30
MDA110-20 110 (100) 2000 2.6 33 8 1.55/330 0.85 1.88 0.33 150 115 92x20x30
MDA110-22 110 (100) 2200 2.6 33 8 1.55/330 0.85 1.88 0.33 150 115 92x20x30
MDA110-24 110 (100) 2400 2.6 33 8 1.55/330 0.85 1.88 0.33 150 115 92x20x30
MDA110-26 110 (100) 2600 2.6 33 20 2.25/330 0.95 1.76 0.31 150 320 94x36x30
MDA110-28 110 (100) 2800 2.6 33 20 2.25/330 0.95 1.76 0.31 150 320 94x36x30
MDA110-30 110 (100) 3000 2.6 33 20 2.25/330 0.95 1.76 0.31 150 320 94x36x30
MDA110-32 110 (100) 3200 2.6 33 20 2.25/330 0.95 1.76 0.31 150 320 94x36x30
MDA110-34 110 (100) 3400 2.6 33 20 2.25/330 0.95 1.76 0.31 150 320 94x36x30
MDA110-36 110 (100) 3600 2.6 33 20 2.25/330 0.95 1.76 0.31 150 320 94x36x30
MDA135-10 135 (100) 1000 3.9 76 12 1.38/410 0.8 1.18 0.31 150 320 94x36x30
MDA135-12 135 (100) 1200 3.9 76 12 1.38/410 0.8 1.18 0.31 150 320 94x36x30
MDA135-14 135 (100) 1400 3.9 76 12 1.38/410 0.8 1.18 0.31 150 320 94x36x30
MDA135-16 135 (100) 1600 3.9 76 12 1.38/410 0.8 1.18 0.31 150 320 94x36x30
MDA135-18 135 (100) 1800 3.9 76 12 1.38/410 0.8 1.18 0.31 150 320 94x36x30
MDA135-19 135 (100) 1900 3.9 76 12 1.48/410 0.83 1.23 0.3 150 320 94x36x30
MDA135-20 135 (100) 2000 3.9 76 12 1.48/410 0.83 1.23 0.3 150 320 94x36x30
MDA135-22 135 (100) 2200 3.9 76 12 1.48/410 0.83 1.23 0.3 150 320 94x36x30
MDA135-24 135 (100) 2400 3.9 76 12 1.48/410 0.83 1.23 0.3 150 320 94x36x30
MDA135-26 135 (100) 2600 3.9 76 20 1.98/410 0.85 1.01 0.29 150 320 94x36x30
MDA135-28 135 (100) 2800 3.9 76 20 1.98/410 0.85 1.01 0.29 150 320 94x36x30
MDA135-30 135 (100) 3000 3.9 76 20 1.98/410 0.85 1.01 0.29 150 320 94x36x30
MDA135-32 135 (100) 3200 3.9 76 20 1.98/410 0.85 1.01 0.29 150 320 94x36x30
MDA135-34 135 (100) 3400 3.9 76 20 1.98/410 0.85 1.01 0.29 150 320 94x36x30
MDA135-36 135 (100) 3600 3.9 76 20 1.98/410 0.85 1.01 0.29 150 320 94x36x30
MDA160-10 160 (100) 1000 4.6 106 12 1.56/480 0.8 1.35 0.23 150 320 94x36x30
MDA160-12 160 (100) 1200 4.6 106 12 1.56/480 0.8 1.35 0.23 150 320 94x36x30
MDA160-14 160 (100) 1400 4.6 106 12 1.56/480 0.8 1.35 0.23 150 320 94x36x30
MDA160-16 160 (100) 1600 4.6 106 12 1.56/480 0.8 1.35 0.23 150 320 94x36x30
MDA160-18 160 (100) 1800 4.6 106 12 1.56/480 0.8 1.35 0.23 150 320 94x36x30
MDA160-19 160 (100) 1900 4.6 105 12 1.66/480 0.84 1.31 0.23 150 320 94x36x30
MDA160-20 160 (100) 2000 4.6 105 12 1.66/480 0.84 1.31 0.23 150 320 94x36x30
MDA160-22 160 (100) 2200 4.6 105 12 1.66/480 0.84 1.31 0.23 150 320 94x36x30
MDA160-24 160 (100) 2400 4.6 105 12 1.66/480 0.84 1.31 0.23 150 320 94x36x30
MDA160-26 160 (100) 2600 4.8 106 25 1.98/480 0.95 0.9 0.23 150 320 94x36x30
MDA160-28 160 (100) 2800 4.8 106 25 1.98/480 0.95 0.9 0.23 150 320 94x36x30
MDA160-30 160 (100) 3000 4.8 106 25 1.98/480 0.95 0.9 0.23 150 320 94x36x30
MDA160-32 160 (100) 3200 4.8 106 25 1.98/480 0.95 0.9 0.23 150 320 94x36x30
MDA160-34 160 (100) 3400 4.8 106 25 1.98/480 0.95 0.9 0.23 150 320 94x36x30
MDA160-36 160 (100) 3600 4.8 106 25 1.98/480 0.95 0.9 0.23 150 320 94x36x30
MDA182-10 182 (100) 1000 6.4 205 12 1.43/550 0.8 0.96 0.22 150 320 94x36x30
MDA182-12 182 (100) 1200 6.4 205 12 1.43/550 0.8 0.96 0.22 150 320 94x36x30
MDA182-14 182 (100) 1400 6.4 205 12 1.43/550 0.8 0.96 0.22 150 320 94x36x30
MDA182-16 182 (100) 1600 6.4 205 12 1.43/550 0.8 0.96 0.22 150 320 94x36x30
MDA182-18 182 (100) 1800 6.4 205 12 1.43/550 0.8 0.96 0.22 150 320 94x36x30
MDA182-19 160 (100) 1900 6.4 204 12 1.73/550 0.85 1.05 0.2 150 320 94x36x30
MDA182-20 160 (100) 2000 6.4 204 12 1.73/550 0.85 1.05 0.2 150 320 94x36x30
MDA182-22 160 (100) 2200 6.4 204 12 1.73/550 0.85 1.05 0.2 150 320 94x36x30
MDA182-24 160 (100) 2400 6.4 204 12 1.73/550 0.85 1.05 0.2 150 320 94x36x30
MDA200-10 200 (100) 1000 7.5 281 12 1.38/600 0.75 0.88 0.21 150 320 94x36x30
MDA200-12 200 (100) 1200 7.5 281 12 1.38/600 0.75 0.88 0.21 150 320 94x36x30
MDA200-14 200 (100) 1400 7.5 281 12 1.38/600 0.75 0.88 0.21 150 320 94x36x30
MDA200-16 200 (100) 1600 7.5 281 12 1.38/600 0.75 0.88 0.21 150 320 94x36x30
MDA200-18 200 (100) 1800 7.5 281 12 1.38/600 0.75 0.88 0.21 150 320 94x36x30
MDA200-19 200 (100) 1900 7.5 281 12 1.48/600 0.82 0.96 0.18 150 320 94x36x30
MDA200-20 200 (100) 2000 7.5 281 12 1.48/600 0.82 0.96 0.18 150 320 94x36x30
MDA200-22 200 (100) 2200 7.5 281 12 1.48/600 0.82 0.96 0.18 150 320 94x36x30
MDA200-24 200 (100) 2400 7.5 281 12 1.48/600 0.82 0.96 0.18 150 320 94x36x30
MDA200-26 200 (100) 2600 7.5 281 30 2.10/600 0.95 1.4 0.15 150 860 92x50x50
MDA200-28 200 (100) 2800 7.5 281 30 2.10/600 0.95 1.4 0.15 150 860 92x50x50
MDA200-30 200 (100) 3000 7.5 281 30 2.10/600 0.95 1.4 0.15 150 860 92x50x50
MDA200-32 200 (100) 3200 7.5 281 30 2.10/600 0.95 1.4 0.15 150 860 92x50x50
MDA200-34 200 (100) 3400 7.5 281 30 2.10/600 0.95 1.4 0.15 150 860 92x50x50
MDA200-36 200 (100) 3600 7.5 281 30 2.10/600 0.95 1.4 0.15 150 860 92x50x50
MDA250-10 250 (100) 1000 9.5 451 20 1.43/750 0.75 0.76 0.14 150 860 92x50x50
MDA250-12 250 (100) 1200 9.5 451 20 1.43/750 0.75 0.76 0.14 150 860 92x50x50
MDA250-14 250 (100) 1400 9.5 451 20 1.43/750 0.75 0.76 0.14 150 860 92x50x50
MDA250-16 250 (100) 1600 9.5 451 20 1.43/750 0.75 0.76 0.14 150 860 92x50x50
MDA250-18 250 (100) 1800 9.5 451 20 1.43/750 0.75 0.76 0.14 150 860 92x50x50
MDA250-19 250 (100) 1900 9.5 451 20 1.53/750 0.85 0.89 0.13 150 860 92x50x50
MDA250-20 250 (100) 2000 9.5 451 20 1.53/750 0.85 0.89 0.13 150 860 92x50x50
MDA250-22 250 (100) 2200 9.5 451 20 1.53/750 0.85 0.89 0.13 150 860 92x50x50
MDA250-24 250 (100) 2400 9.5 451 20 1.53/750 0.85 0.89 0.13 150 860 92x50x50
MDA250-26 250 (100) 2600 9.5 451 30 1.83/750 0.95 0.87 0.13 150 860 92x50x50
MDA250-28 250 (100) 2800 9.5 451 30 1.83/750 0.95 0.87 0.13 150 860 92x50x50
MDA250-30 250 (100) 3000 9.5 451 30 1.83/750 0.95 0.87 0.13 150 860 92x50x50
MDA250-32 250 (100) 3200 9.5 451 30 1.83/750 0.95 0.87 0.13 150 860 92x50x50
MDA250-34 250 (100) 3400 9.5 451 30 1.83/750 0.95 0.87 0.13 150 860 92x50x50
MDA250-36 250 (100) 3600 9.5 451 30 1.83/750 0.95 0.87 0.13 150 860 92x50x50
MDA285-10 285 (100) 1000 9.5 451 20 1.40/750 0.75 0.7 0.14 150 860 92x50x50
MDA285-12 285 (100) 1200 9.5 451 20 1.40/750 0.75 0.7 0.14 150 860 92x50x50
MDA285-14 285 (100) 1400 9.5 451 20 1.40/750 0.75 0.7 0.14 150 860 92x50x50
MDA285-16 285 (100) 1600 9.5 451 20 1.40/750 0.75 0.7 0.14 150 860 92x50x50
MDA285-18 285 (100) 1800 9.5 451 20 1.40/750 0.75 0.7 0.14 150 860 92x50x50
MDA300-10 300 (100) 1000 10 500 20 1.35/900 0.75 0.55 0.13 150 860 92x50x50
MDA300-12 300 (100) 1200 10 500 20 1.35/900 0.75 0.55 0.13 150 860 92x50x50
MDA300-14 300 (100) 1400 10 500 20 1.35/900 0.75 0.55 0.13 150 860 92x50x50
MDA300-16 300 (100) 1600 10 500 20 1.35/900 0.75 0.55 0.13 150 860 92x50x50
MDA300-18 300 (100) 1800 10 500 20 1.35/900 0.75 0.55 0.13 150 860 92x50x50
MDA300-19 300 (100) 1900 10 500 20 1.45/900 0.8 0.5 0.12 150 860 92x50x50
MDA300-20 300 (100) 2000 10 500 20 1.45/900 0.8 0.5 0.12 150 860 92x50x50
MDA300-22 300 (100) 2200 10 500 20 1.45/900 0.8 0.5 0.12 150 860 92x50x50
MDA300-24 300 (100) 2400 10 500 20 1.45/900 0.8 0.5 0.12 150 860 92x50x50
MDA300-26 300 (100) 2600 10 500 45 1.85/900 0.95 0.7 0.11 150 1350 108x62x52
MDA300-28 300 (100) 2800 10 500 45 1.85/900 0.95 0.7 0.11 150 1350 108x62x52
MDA300-30 300 (100) 3000 10 500 45 1.85/900 0.95 0.7 0.11 150 1350 108x62x52
MDA300-32 300 (100) 3200 10 500 45 1.85/900 0.95 0.7 0.11 150 1350 108x62x52
MDA300-34 300 (100) 3400 10 500 45 1.85/900 0.95 0.7 0.11 150 1350 108x62x52
MDA300-36 300 (100) 3600 10 500 45 1.85/900 0.95 0.7 0.11 150 1350 108x62x52
MDA350-10 350 (100) 1000 12 720 30 1.50/1050 0.75 0.61 0.11 150 1350 108x62x52
MDA350-12 350 (100) 1200 12 720 30 1.50/1050 0.75 0.61 0.11 150 1350 108x62x52
MDA350-14 350 (100) 1400 12 720 30 1.50/1050 0.75 0.61 0.11 150 1350 108x62x52
MDA350-16 350 (100) 1600 12 720 30 1.50/1050 0.75 0.61 0.11 150 1350 108x62x52
MDA350-18 350 (100) 1800 12 720 30 1.50/1050 0.75 0.61 0.11 150 1350 108x62x52
MDA350-19 350 (100) 1900 12 720 30 1.60/1050 0.8 0.56 0.11 150 1350 108x62x52
MDA350-20 350 (100) 2000 12 720 30 1.60/1050 0.8 0.56 0.11 150 1350 108x62x52
MDA350-22 350 (100) 2200 12 720 30 1.60/1050 0.8 0.56 0.11 150 1350 108x62x52
MDA350-24 350 (100) 2400 12 720 30 1.60/1050 0.8 0.56 0.11 150 1350 108x62x52
MDA400-10 400 (100) 1000 13 845 30 1.48/1200 0.75 0.5 0.1 150 1350 108x62x52
MDA400-12 400 (100) 1200 13 845 30 1.48/1200 0.75 0.5 0.1 150 1350 108x62x52
MDA400-14 400 (100) 1400 13 845 30 1.48/1200 0.75 0.5 0.1 150 1350 108x62x52
MDA400-16 400 (100) 1600 13 845 30 1.48/1200 0.75 0.5 0.1 150 1350 108x62x52
MDA400-18 400 (100) 1800 13 845 30 1.48/1200 0.75 0.5 0.1 150 1350 108x62x52
MDA400-19 400 (100) 1900 13 845 30 1.55/1200 0.85 0.49 0.09 150 1350 108x62x52
MDA400-20 400 (100) 2000 13 845 30 1.55/1200 0.85 0.49 0.09 150 1350 108x62x52
MDA400-22 400 (100) 2200 13 845 30 1.55/1200 0.85 0.49 0.09 150 1350 108x62x52
MDA400-24 400 (100) 2400 13 845 30 1.55/1200 0.85 0.49 0.09 150 1350 108x62x52
MDA400-26 400 (400) 2600 13 845 30 1.65/1200 0.95 0.72 0.075 150 2300 135x76x62
MDA400-28 400 (400) 2800 13 845 30 1.65/1200 0.95 0.72 0.075 150 2300 135x76x62
MDA400-30 400 (400) 3000 13 845 30 1.65/1200 0.95 0.72 0.075 150 2300 135x76x62
MDA400-32 400 (400) 3200 13 845 30 1.65/1200 0.95 0.72 0.075 150 2300 135x76x62
MDA400-34 400 (400) 3400 13 845 30 1.65/1200 0.95 0.72 0.075 150 2300 135x76x62
MDA400-36 400 (400) 3600 13 845 30 1.65/1200 0.95 0.72 0.075 150 2300 135x76x62
MDA400-10-W 400 (60) 1000 13 845 30 1.65/1200 0.75 0.64 0.15 125 1300 92x50x57
MDA400-12-W 400 (60) 1200 13 845 30 1.65/1200 0.75 0.64 0.15 125 1300 92x50x57
MDA400-14-W 400 (60) 1400 13 845 30 1.65/1200 0.75 0.64 0.15 125 1300 92x50x57
MDA400-16-W 400 (60) 1600 13 845 30 1.65/1200 0.75 0.64 0.15 125 1300 92x50x57
MDA400-18-W 400 (60) 1800 13 845 30 1.65/1200 0.75 0.64 0.15 125 1300 92x50x57
MDA400-19-W 400 (60) 1900 13 845 30 1.88/1200 0.85 0.69 0.14 125 1300 92x50x57
MDA400-20-W 400 (60) 2000 13 845 30 1.88/1200 0.85 0.69 0.14 125 1300 92x50x57
MDA400-22-W 400 (60) 2200 13 845 30 1.88/1200 0.85 0.69 0.14 125 1300 92x50x57
MDA400-24-W 400 (60) 2400 13 845 30 1.88/1200 0.85 0.69 0.14 125 1300 92x50x57
MDA400-26-W 400 (400) 2600 13 845 35 2.41/1200 0.95 1.05 0.11 125 1820 108x62x58
MDA400-28-W 400 (400) 2800 13 845 35 2.41/1200 0.95 1.05 0.11 125 1820 108x62x58
MDA400-30-W 400 (400) 3000 13 845 35 2.41/1200 0.95 1.05 0.11 125 1820 108x62x58
MDA400-32-W 400 (400) 3200 13 845 35 2.41/1200 0.95 1.05 0.11 125 1820 108x62x58
MDA400-34-W 400 (400) 3400 13 845 35 2.41/1200 0.95 1.05 0.11 125 1820 108x62x58
MDA400-36-W 400 (400) 3600 13 845 35 2.41/1200 0.95 1.05 0.11 125 1820 108x62x58
MDA500-10 500 (100) 1000 16 1280 40 1.45/1500 0.75 0.3 0.09 125 2300 135x76x62
MDA500-12 500 (100) 1200 16 1280 40 1.45/1500 0.75 0.3 0.09 125 2300 135x76x62
MDA500-14 500 (100) 1400 16 1280 40 1.45/1500 0.75 0.3 0.09 125 2300 135x76x62
MDA500-16 500 (100) 1600 16 1280 40 1.45/1500 0.75 0.3 0.09 125 2300 135x76x62
MDA500-18 500 (100) 1800 16 1280 40 1.45/1500 0.75 0.3 0.09 125 2300 135x76x62
MDA500-19 500 (100) 1900 16 1280 40 1.35/1500 0.85 0.38 0.075 125 2040 124x66x64
MDA500-20 500 (100) 2000 16 1280 40 1.35/1500 0.85 0.38 0.075 125 2040 124x66x64
MDA500-22 500 (100) 2200 16 1280 40 1.35/1500 0.85 0.38 0.075 125 2040 124x66x64
MDA500-24 500 (100) 2400 16 1280 40 1.35/1500 0.85 0.38 0.075 125 2040 124x66x64
MDA500-10-W 500 (60) 1000 16 1280 40 1.68/1500 0.75 0.51 0.13 150 1820 108x62x58
MDA500-12-W 500 (60) 1200 16 1280 40 1.68/1500 0.75 0.51 0.13 150 1820 108x62x58
MDA500-14-W 500 (60) 1400 16 1280 40 1.68/1500 0.75 0.51 0.13 150 1820 108x62x58
MDA500-16-W 500 (60) 1600 16 1280 40 1.68/1500 0.75 0.51 0.13 150 1820 108x62x58
MDA500-18-W 500 (60) 1800 16 1280 40 1.68/1500 0.75 0.51 0.13 150 1820 108x62x58
MDA500-19-W 500 (60) 1900 16 1280 40 1.85/1500 0.85 0.53 0.12 150 1820 108x62x58
MDA500-20-W 500 (60) 2000 16 1280 40 1.85/1500 0.85 0.53 0.12 150 1820 108x62x58
MDA500-22-W 500 (60) 2200 16 1280 40 1.85/1500 0.85 0.53 0.12 150 1820 108x62x58
MDA500-24-W 500 (60) 2400 16 1280 40 1.85/1500 0.85 0.53 0.12 150 1820 108x62x58
MDA500-26-W 500 (60) 2600 16 1280 45 2.83/1500 0.95 1.12 0.075 150 2600 135x76x68
MDA500-28-W 500 (60) 2800 16 1280 45 2.83/1500 0.95 1.12 0.075 150 2600 135x76x68
MDA500-30-W 500 (60) 3000 16 1280 45 2.83/1500 0.95 1.12 0.075 150 2600 135x76x68
MDA500-32-W 500 (60) 3200 16 1280 45 2.83/1500 0.95 1.12 0.075 150 2600 135x76x68
MDA500-34-W 500 (60) 3400 16 1280 45 2.83/1500 0.95 1.12 0.075 150 2600 135x76x68
MDA500-36-W 500 (60) 3600 16 1280 45 2.83/1500 0.95 1.12 0.075 150 2600 135x76x68
MDA57-10 570 (100) 1000 18 1620 40 1.45/1500 0.75 0.3 0.09 150 1300 124x60x51
MDA570-12 570 (100) 1200 18 1620 40 1.45/1500 0.75 0.3 0.09 150 1300 124x60x51
MDA570-14 570 (100) 1400 18 1620 40 1.45/1500 0.75 0.3 0.09 150 1300 124x60x51
MDA570-16 570 (100) 1600 18 1620 40 1.45/1500 0.75 0.3 0.09 150 1300 124x60x51
MDA570-18 570 (100) 1800 18 1620 40 1.45/1500 0.75 0.3 0.09 150 1300 124x60x51
MDA600-10 600 (100) 1000 19 1805 45 1.50/1800 0.75 0.28 0.065 150 2300 135x76x62
MDA600-12 600 (100) 1200 19 1805 45 1.50/1800 0.75 0.28 0.065 150 2300 135x76x62
MDA600-14 600 (100) 1400 19 1805 45 1.50/1800 0.75 0.28 0.065 150 2300 135x76x62
MDA600-16 600 (100) 1600 19 1805 45 1.50/1800 0.75 0.28 0.065 150 2300 135x76x62
MDA600-18 600 (100) 1800 19 1805 45 1.50/1800 0.75 0.28 0.065 150 2300 135x76x62
MDA600-19 600 (100) 1900 19 1805 40 1.53/1800 0.75 0.32 0.065 150 2300 135x76x62
MDA600-20 600 (100) 2000 19 1805 40 1.53/1800 0.75 0.32 0.065 150 2300 135x76x62
MDA600-22 600 (100) 2200 19 1805 40 1.53/1800 0.75 0.32 0.065 150 2300 135x76x62
MDA600-24 600 (100) 2400 19 1805 40 1.53/1800 0.75 0.32 0.065 150 2300 135x76x62
MDA600-10-W 600 (60) 1000 19 1805 40 1.70/1800 0.75 0.42 0.11 125 1820 108x62x58
MDA600-12-W 600 (60) 1200 19 1805 40 1.70/1800 0.75 0.42 0.11 125 1820 108x62x58
MDA600-14-W 600 (60) 1400 19 1805 40 1.70/1800 0.75 0.42 0.11 125 1820 108x62x58
MDA600-16-W 600 (60) 1600 19 1805 40 1.70/1800 0.75 0.42 0.11 125 1820 108x62x58
MDA600-18-W 600 (60) 1800 19 1805 40 1.70/1800 0.75 0.42 0.11 125 1820 108x62x58
MDA600-19-W 600 (60) 1900 19 1805 40 1.84/1800 0.85 0.44 0.1 125 1820 108x62x58
MDA600-20-W 600 (60) 2000 19 1805 40 1.84/1800 0.85 0.44 0.1 125 1820 108x62x58
MDA600-22-W 600 (60) 2200 19 1805 40 1.84/1800 0.85 0.44 0.1 125 1820 108x62x58
MDA600-24-W 600 (60) 2400 19 1805 40 1.84/1800 0.85 0.44 0.1 125 1820 108x62x58
MDA600-26-W 600 (60) 2600 19 1805 45 2.79/1800 0.95 0.91 0.065 125 2600 135x76x68
MDA600-28-W 600 (60) 2800 19 1805 45 2.79/1800 0.95 0.91 0.065 125 2600 135x76x68
MDA600-30-W 600 (60) 3000 19 1805 45 2.79/1800 0.95 0.91 0.065 125 2600 135x76x68
MDA600-32-W 600 (60) 3200 19 1805 45 2.79/1800 0.95 0.91 0.065 125 2600 135x76x68
MDA600-34-W 600 (60) 3400 19 1805 45 2.79/1800 0.95 0.91 0.065 125 2600 135x76x68
MDA600-36-W 600 (60) 3600 19 1805 45 2.79/1800 0.95 0.91 0.065 125 2600 135x76x68
MDA800-10 800 (100) 1000 22 2420 45 1.80/2400 0.72 0.18 0.058 150 3500 150x76x78
MDA800-12 800 (100) 1200 22 2420 45 1.80/2400 0.72 0.18 0.058 150 3500 150x76x78
MDA800-14 800 (100) 1400 22 2420 45 1.80/2400 0.72 0.18 0.058 150 3500 150x76x78
MDA800-16 800 (100) 1600 22 2420 45 1.80/2400 0.72 0.18 0.058 150 3500 150x76x78
MDA800-18 800 (100) 1800 22 2420 45 1.80/2400 0.72 0.18 0.058 150 3500 150x76x78
MDA800-19 800 (100) 1900 22 2420 45 1.38/2400 0.7 0.20  0.058 150 2300 135x76x62
MDA800-20 800 (100) 2000 22 2420 45 1.38/2400 0.7 0.20  0.058 150 2300 135x76x62
MDA800-22 800 (100) 2200 22 2420 45 1.38/2400 0.7 0.20  0.058 150 2300 135x76x62
MDA800-24 800 (100) 2400 22 2420 45 1.38/2400 0.7 0.20  0.058 150 2300 135x76x62
MDA800-10-W 800 (60) 1000 22 2420 40 1.72/2400 0.75 0.34 0.08 150 2600 135x76x68
MDA800-12-W 800 (60) 1200 22 2420 40 1.72/2400 0.75 0.34 0.08 150 2600 135x76x68
MDA800-14-W 800 (60) 1400 22 2420 40 1.72/2400 0.75 0.34 0.08 150 2600 135x76x68
MDA800-16-W 800 (60) 1600 22 2420 40 1.72/2400 0.75 0.34 0.08 150 2600 135x76x68
MDA800-18-W 800 (60) 1800 22 2420 40 1.72/2400 0.75 0.34 0.08 150 2600 135x76x68
MDA800-19-W 800 (60) 1900 22 2420 45 1.86/2400 0.8 0.36 0.075 150 2600 135x76x68
MDA800-20-W 800 (60) 2000 22 2420 45 1.86/2400 0.8 0.36 0.075 150 2600 135x76x68
MDA800-22-W 800 (60) 2200 22 2420 45 1.86/2400 0.8 0.36 0.075 150 2600 135x76x68
MDA800-24-W 800 (60) 2400 22 2420 45 1.86/2400 0.8 0.36 0.075 150 2600 135x76x68
MDA1000-10 1000 (100) 1000 28 3920 50 1.82/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-12 1000 (100) 1200 28 3920 50 1.82/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-14 1000 (100) 1400 28 3920 50 1.82/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-16 1000 (100) 1600 28 3920 50 1.82/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-18 1000 (100) 1800 28 3920 50 1.82/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-19 1000 (100) 1900 28 3920 50 1.21/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-20 1000 (100) 2000 28 3920 50 1.21/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-22 1000 (100) 2200 28 3920 50 1.21/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-24 1000 (100) 2400 28 3920 50 1.21/3000 0.71 0.10  0.052 150 3800 150x77x83
MDA1000-10-W 1000 (60) 1000 28 3920 40 1.82/3000 0.75 0.25 0.065 150 3600 150x76x78
MDA1000-12-W 1000 (60) 1200 28 3920 40 1.82/3000 0.75 0.25 0.065 150 3600 150x76x78
MDA1000-14-W 1000 (60) 1400 28 3920 40 1.82/3000 0.75 0.25 0.065 150 3600 150x76x78
MDA1000-16-W 1000 (60) 1600 28 3920 40 1.82/3000 0.75 0.25 0.065 150 3600 150x76x78
MDA1000-18-W 1000 (60) 1800 28 3920 40 1.82/3000 0.75 0.25 0.065 150 3600 150x76x78
MDA1000-19-W 1000 (60) 1900 28 3920 50 2.16/3000 0.82 0.38 0.048 150 3600 150x76x78
MDA1000-20-W 1000 (60) 2000 28 3920 50 2.16/3000 0.82 0.38 0.048 150 3600 150x76x78
MDA1000-22-W 1000 (60) 2200 28 3920 50 2.16/3000 0.82 0.38 0.048 150 3600 150x76x78
MDA1000-24-W 1000 (60) 2400 28 3920 50 2.16/3000 0.82 0.38 0.048 150 3600 150x76x78
MDA1200-10 1200 (100) 1000 34 5780 50 1.86/3000 0.71 0.11 0.04 150 3800 150x77x83
MDA1200-12 1200 (100) 1200 34 5780 50 1.86/3000 0.71 0.11 0.04 150 3800 150x77x83
MDA1200-14 1200 (100) 1400 34 5780 50 1.86/3000 0.71 0.11 0.04 150 3800 150x77x83
MDA1200-16 1200 (100) 1600 34 5780 50 1.86/3000 0.71 0.11 0.04 150 3800 150x77x83
MDA1200-18 1200 (100) 1800 34 5780 50 1.86/3000 0.71 0.11 0.04 150 3800 150x77x83
MDA1200-19 1200 (100) 1900 34 5780 50 1.20/3000 0.71 0 0.042 150 3800 150x77x83
MDA1200-20 1200 (100) 2000 34 5780 50 1.20/3000 0.71 0 0.042 150 3800 150x77x83
MDA1200-22 1200 (100) 2200 34 5780 50 1.20/3000 0.71 0 0.042 150 3800 150x77x83
MDA1200-24 1200 (100) 2400 34 5780 50 1.20/3000 0.71 0 0.042 150 3800 150x77x83
Copyright © Greegoo Electric Co., Ltd.
Privacy Policy | XML
Submit

Chat through WhatsApp Now

Chat through Wechat Now

GreegooChina@Gmail.com

Send an Enquiry

We value your privacy

We use cookies to enhance your browsing experience, serve personalized ads or content, and analyze our traffic. By clicking "Accept All", you consent to our use of cookies.

Consent Preferences

Consent Preferences
