A1 3 phase bridge double chopper
Home Products IGBT Power Module IGBT Module HousingA1 3 phase bridge double chopper
Product Details
A1 3 phase bridge double chopper
| Type | VCES | IC | VCE(sat) | E(on off) | Rth(J-C) | Packages |
| Tc=25℃ | Tc=80℃ | Tj=25℃ | Tj=125℃ | |||
| (V) | (A) | (V) | (mJ) | (K/W) | ||
| G450CH120TE | 1200 | 450 | 1.9 | 93 | 0.04 | A1 |
| G600CH120TE | 1200 | 600 | 1.9 | 138 | 0.03 | A1 |
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
