15A to 60A IGBT module
Home Products IGBT Power Module IGBT Module Housing15A to 60A IGBT module
15A to 60A IGBT module
|
TYPE |
Collector Emmiter Voltage |
CD collect current |
Gate emitter voltage |
Diode thermal resistance junction case MAX |
Collector emitter saturation voltage |
Gate emitter threshold voltage |
Diode forward voltage |
|
VCE(V) |
IC(A) |
VGE(V) |
RthJC(℃ /W) |
VCEsat(V) |
VGE(TH)(V) |
VF(V) |
|
|
W15HA120-1 |
1200 |
15 |
±20 |
0.8 |
2.1 |
7 |
3.5 |
|
W20HA120-1 |
1200 |
20 |
±20 |
0.8 |
2.1 |
7 |
3.5 |
|
W25HA120-1 |
1200 |
25 |
±20 |
0.8 |
2.1 |
7 |
3.5 |
|
W40HA120-1 |
1200 |
40 |
±20 |
0.8 |
2.1 |
7 |
5 |
|
W40HA60-1 |
600 |
40 |
±20 |
0.8 |
2.1 |
7 |
3.5 |
|
W60HA60-1 |
600 |
60 |
±20 |
0.8 |
2.1 |
7 |
3.5 |
