Specification
T508N Phase Control Thyristor Infineon
Part Numbers | Unit | T508N12TOF | T508N16TOF | T508N18TOF |
Maximum Allowable Average Forward Current (Case Temperature) IT(AV) (TC) |
A (85ºC) | 510 | 510 | 510 |
Repetitive Pulsed Closed State Voltage; Repetitive Pulsed Reverse Voltage VDRM/VRRM |
V | 1200 | 1600 | 1800 |
RMS On-State Current ITRMSM | A | 800 | 800 | 800 |
Surge On-State Current ITSM | kA | 6.9 | 6.9 | 6.9 |
Safety Factor I²t | kA²·s | 238 | 238 | 238 |
Threshold Voltage VT0 | V | 0.8 | 0.8 | 0.8 |
On-State Slope Resistance rT | mΩ | 0.6 | 0.6 | 0.6 |
Critical Rate of Rise of On-State Current (diT/dt)cr | A/µs | 120 | 120 | 120 |
Turn-Off Time, Max tq | µs | 250 | 250 | 250 |
Critical Rate of Rise of Off-State Voltage, Min (dVD/dt)cr | V/µs | 1000 | 1000 | 1000 |
Gate Trigger Direct Voltage, Max VGT | V | 2 | 2 | 2 |
Gate Trigger Direct Current, Max IGT | mA | 200 | 200 | 200 |
Temperature of P-N Junction Tvj Max | ºC | 125 | 125 | 125 |
Thermal Resistance, Junction to Case Rth(j-c) | ºC/W | 0.053 | 0.053 | 0.053 |
Dimensions ØD×Ød×H | mm | 50x30x14 | 50x30x14 | 50x30x14 |
