T2-160-10 Rotor Thyristor

Features:

▪ Soldered design
▪ Epoxy case with adsorbent
▪ By means of special arrangement centrifugal forces are applied not to silicon chip but to case, providing safe operation in large mechanical force conditions

Applications:

▪ Brushless excitation systems of large electric machines. Thyristors can operate by long time axial centrifugal accelerations up to 5000g (sort time up to 7000g) in base plate direction and long time lateral accelerations up to 1000g (short time up to 1500g)
