Single Phase Diode Bridge Rectifiers SKB
The diode bridges are housed in a standard industrial case making it easy to easy integrate of the device into existing equipment.
Single Phase Diode Bridges are used in various power equipment - rectifier for power supplies; input rectifier for variable frequency drives; rectifier for DC motor field supplies; battery charger rectifiers; single phase rectifiers for power supplies; non-controlled DC motor field supply; DC power supply, for transistorized AC motor controllers.
Type | ID (Tc,℃) |
VRRM VDRM |
ITSM | I²t | VT(T0) | rT | Tvj max | Rth(-c) | W | Package, Dimensions LxBxH |
A | V | A | kA² · s | V | mΩ | ℃ | K/W | g | mm | |
SKB25/01 | 17(75) | 100 | 320 | 500 | 0.85 | 12 | 150 | 2 | 24 | G10b 29x29x10 |
SKB25/02 | 200 | |||||||||
SKB25/04 | 400 | |||||||||
SKB25/06 | 600 | |||||||||
SKB25/08 | 800 | |||||||||
SKB25/12 | 1200 | |||||||||
SKB25/14 | 1400 | |||||||||
SKB25/16 | 1600 | |||||||||
SKB26/02 | 18(75) | 200 | 320 | 500 | 0.85 | 12 | 150 | 1.9 | 20 | G50a 29x29x10 |
SKB26/04 | 400 | |||||||||
SKB26/06 | 600 | |||||||||
SKB26/08 | 800 | |||||||||
SKB26/10 | 800 | |||||||||
SKB26/12 | 1200 | |||||||||
SKB26/14 | 1400 | |||||||||
SKB26/16 | 1600 | |||||||||
SKB28/02 | 28(85) | 200 | 320 | 510 | 0.85 | 12 | 125 | 2 | 66 | Package 1 63x32x22 |
SKB28/04 | 400 | |||||||||
SKB28/08 | 800 | |||||||||
SKB28/12 | 1200 | |||||||||
SKB28/14 | 1400 | |||||||||
SKB28/16 | 1600 | |||||||||
SKB30/02A1 | 30 (94) | 200 | 320 | 500 | 0.85 | 12 | 150 | 0.7 | 125 | G12 55x45x24 |
SKB30/04A1 | 400 | |||||||||
SKB30/08A1 | 800 | |||||||||
SKB30/12A1 | 1200 | |||||||||
SKB30/14A1 | 1400 | |||||||||
SKB30/16A1 | 1600 | |||||||||
SKB35/04 | 35(29) | 400 | 330 | 540 | 0.85 | 7 | 150 | 1.5 | 18 | G10b 29x29x10 |
SKB35/08 | 800 | |||||||||
SKB35/10 | 1000 | |||||||||
SKB35/12 | 1200 | |||||||||
SKB35/16 | 1600 | |||||||||
SKB52/04 | 50(99) | 400 | 425 | 900 | 0.85 | 8 | 150 | 1.5 | 165 | Package 3 72x42x30 |
SKB52/08 | 800 | |||||||||
SKB52/12 | 1200 | |||||||||
SKB52/14 | 1400 | |||||||||
SKB52/16 | 1600 | |||||||||
SKB52/18 | 1800 | |||||||||
SKB60/04 | 60 (88) | 400 | 850 | 3600 | 0.85 | 5 | 125 | 1 | 165 | Package 2 65x48x36 |
SKB60/08 | 800 | |||||||||
SKB60/12 | 1200 | |||||||||
SKB60/14 | 1400 | |||||||||
SKB60/16 | 1600 | |||||||||
SKB72/04 | 70(101) | 400 | 640 | 2000 | 0.85 | 5 | 150 | 1.1 | 165 | Package 3 72x42x30 |
SKB72/08 | 800 | |||||||||
SKB72/12 | 1200 | |||||||||
SKB72/14 | 1400 | |||||||||
SKB72/16 | 1600 | |||||||||
SKB72/18 | 1800 |
