SCR Voltage Regulator three phase 150A and 175A
Home Products SCR Power ControllerHGW3 Analog Indicator Basic typeSCR Voltage Regulator three phase 150A and 175A
Specification
SCR Voltage Regulator three phase 150A and 175A
| Mode | Phase | Input Voltage | Max. Current |
Load(KW) | Weight (KG) |
Control mode | Control signal | |
| 220V | 380V | |||||||
| HGW3-4-4-150-P | 3PH | 330-440V | 150A | 45 | 75 | 5.7 | Phase Angle | 4-20mA |
| HGW3-4-4-175-P | 3PH | 330-440V | 175A | 53 | 88 | 5.7 | Phase Angle | 4-20mA |
| HGW3-4-4-150-P1 | 3PH | 330-440V | 150A | 45 | 75 | 5.7 | Phase Angle | 0-10V |
| HGW3-4-4-175-P1 | 3PH | 330-440V | 175A | 53 | 88 | 5.7 | Phase Angle | 0-10V |
| HGW3-4-2-150-P | 3PH | 100-240V | 150A | 45 | 75 | 5.7 | Phase Angle | 4-20mA |
| HGW3-4-2-175-P | 3PH | 100-240V | 175A | 53 | 88 | 5.7 | Phase Angle | 4-20mA |
| HGW3-4-2-150-P1 | 3PH | 100-240V | 150A | 45 | 75 | 5.7 | Phase Angle | 0-10V |
| HGW3-4-2-175-P1 | 3PH | 100-240V | 175A | 53 | 88 | 5.7 | Phase Angle | 0-10V |
| HGW3-4-8-150-P | 3PH | 480V | 150A | 45 | 75 | 5.7 | Phase Angle | 4-20mA |
| HGW3-4-8-175-P | 3PH | 480V | 175A | 53 | 88 | 5.7 | Phase Angle | 4-20mA |
| HGW3-4-8-150-P1 | 3PH | 480V | 150A | 45 | 75 | 5.7 | Phase Angle | 0-10V |
| HGW3-4-8-175-P1 | 3PH | 480V | 175A | 53 | 88 | 5.7 | Phase Angle | 0-10V |
