СP ОВ 40 Current Transformer
Home Products Voltage & Current TransformerLow Voltage Current TransformersСP ОВ 40 Current Transformer
Product Details
СP ОВ 40 Current Transformer
| Model | Ratio A | Burden VA | Cross core turn number | |
| class 0.5 | class 1.0 | |||
| СP(ОВ) 40 | 100/5 | 2.5 | 2.5 | 1 |
| 150/5 | 3.0 | 3.0 | 1 | |
| 200/5 | 5.0 | 5-10 | 1 | |
| 250/5 | 5-10 | 5-10 | 1 | |
| 300/5 | 5-10 | 5-10 | 1 | |
| 400/5 | 5-10 | 5-10 | 1 | |
| 500/5 | 5-10 | 5-10 | 1 | |
