СP ОВ 30В Current Transformer
| Model | Ratio A | Burden VA | Cross core turn number | |
| class 0.5 | class 1.0 | |||
| СP(ОВ) 30В | 5/5 | 5.0 | 7.5 | 1 |
| 10/5 | 5.0 | 7.5 | 1 | |
| 15/5 | 5.0 | 7.5 | 1 | |
| 20/5 | 5.0 | 7.5 | 1 | |
| 25/5 | 5.0 | 7.5 | 1 | |
| 30/5 | 5.0 | 7.5 | 1 | |
| 50/5 | 5.0 | 7.5 | 1 | |
| 60/5 | 5.0 | 7.5 | 1 | |
| 100/5 | 5.0 | 7.5 | 1 | |
| 150/5 | 5.0 | 7.5 | 1 | |
| 200/5 | 5.0 | 7.5 | 1 | |
| 250/5 | 5.0 | 7.5 | 1 | |
| 300/5 | 5.0 | 7.5 | 1 | |
