ISSR-40DA 60DA 25DA 40AA 25AA 60AA Intelligent SSR Relay

1. Ultra compact size, exquisite and beautiful
2. The installation position is exactly the same as the electronic solid-state relays circulating in the market, which can be directly replaced
3. Metal aluminum alloy base, strong anti-interference performance
4. With automatic heat-dry balance function
5. Automatically sense the working status of the external environment (intelligent mode)

DC to AC SSR

Model	ISSR-15DA	ISSR-25DA	ISSR-40DA	ISSR-60DA
Load Current	15A	25A	40A	60A
Load Voltage	24-480VAC	24-480VAC	24-480VAC	24-480VAC
Control Voltage	3-48VDC	3-48VDC	3-48VDC	3-48VDC
Control Current	3-20mADC	3-20mADC	3-20mADC	3-20mADC
On Voltage	≤1.5VAC	≤1.5VAC	≤1.5VAC	≤1.5VAC
Off-state Leakage Current	≤4mA	≤4mA	≤4mA	≤4mA
Time Off	≤10ms	≤10ms	≤10ms	≤10ms
Dielectric Strength	2500VAC	2500VAC	2500VAC	2500VAC
Insulation Resistance	100MΩ/500VDC	100MΩ/500VDC	100MΩ/500VDC	100MΩ/500VDC
Ambient Temperature	-25℃ ~ 75℃	-25℃ ~ 75℃	-25℃ ~ 75℃	-25℃ ~ 75℃
Mounting Methods	M4 fixed Bolt	M4 fixed Bolt	M4 fixed Bolt	M4 fixed Bolt
The work instructions	Double LED (Green:Working,Red:Breakdown)
Weight	50g	50g	50g	65g

AC to AC SSR

Model	ISSR-25AA	ISSR-40AA	ISSR-50AA	ISSR-60AA
Load Current	25A	40A	50A	60A
Load Voltage	24-480VAC	24-480VAC	24-480VAC	24-480VAC
Control Voltage	80-250VAC	80-250VAC	80-250VAC	80-250VAC
Control Current	3-10mAAC	3-10mAAC	3-10mAAC	3-10mAAC
On Voltage	≤1.5VAC	≤1.5VAC	≤1.5VAC	≤1.5VAC
Off-state Leakage Current	≤4mA	≤4mA	≤4mA	≤4mA
Time Off	≤10ms	≤10ms	≤10ms	≤10ms
Dielectric Strength	2500VAC	2500VAC	2500VAC	2500VAC
Insulation Resistance	100MΩ/500VDC	100MΩ/500VDC	100MΩ/500VDC	100MΩ/500VDC
Ambient Temperature	-25℃ ~ 75℃	-25℃ ~ 75℃	-25℃ ~ 75℃	-25℃ ~ 75℃
Mounting Methods	M4 fixed Bolt	M4 fixed Bolt	M4 fixed Bolt	M4 fixed Bolt
The work instructions	LED	LED	LED	LED
Weight	70g	70g	70g	70g
