DZ1070N22K Single Rectifier Diode Module
Home Products Thyristor Diode ModuleInfineon Thyristor Diode ModulesDZ1070N22K Single Rectifier Diode Module
Product details
DZ1070N22K Single Rectifier Diode Module
Features
- Pressure contact technology for high reliability
- Industial standard package
- Electrically insulated baseplate
- Advanced medium power technology
Typical Applications
- Rectifier for Drives Applications
- Rectifiers for UPS
- Battery chargers
Key Parameter
- VDRM / VRRM: 2200 V
- IFAVM: 1100 A (Tc=100°C)
- IFSM: 41000 A
- VTO: 0.75 V
- rT: 0.073 mΩ
- RthJC: 0.0466 K/W
- Baseplate Size: 70 mm
- Weight: 1950 g
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
