DP-812 Split core Current Transformer
Home Products Low Voltage CTDP seriesDP-812 Split core Current Transformer
Overview
DP-812 Split core Current Transformer
Frequency: 50/60Hz
Withstand voltage: 3kV AC.(1min)
Rated thermal current: 60In
Dynamic stable current: 2.5lth
Rated voltage: 0.72kV AC.
Overload: 0.2Ih
Working temperature range: -10℃ ~ 50℃
Shell flame retardant grade: V0
Accuracy limiting factor: FS5
Secondary current: 5A/1A
Product Details
| Model | Ratio A | Burden VA | |
| Class 0.5 | Class 1.0 | ||
| DP-812 | 500/5 | / | 2.5 |
| 600/5 | / | 2.5 | |
| 750/5 | 2.5 | 5 | |
| 800/5 | 5 | 2.5 | |
| 1000/5 | 7.5 | 3.75 | |
| 1200/5 | 10 | 5 | |
| 1250/5 | 10 | 5 | |
| 1500/5 | 10 | 5 | |
