DP-510 split core current transformer
Home Products Voltage & Current TransformerLow Voltage Current TransformersDP-510 split core current transformer
Product details
DP-510 split core current transformer
| Model | Primary | Secondary | Rated Burden(VA) — Class 1.0 | ||||||||
| Class 3.0 | Class 1.0 | Class 0.5 | |||||||||
| 1.5 | 2.5 | 5 | 1.5 | 2.5 | 5 | 1.5 | 2.5 | 5 | |||
| DP-510 | 250A | 1A、5A | A1 | A2 | — | A4 | — | — | — | — | — |
| DP-510 | 300A | 1A、5A | B1 | B2 | — | B4 | B5 | — | — | — | — |
| DP-510 | 400A | 1A、5A | C1 | C2 | — | C4 | C5 | — | C7 | — | — |
| DP-510 | 500A | 1A、5A | D1 | D2 | D3 | D4 | D5 | — | D7 | — | — |
| DP-510 | 600A | 1A、5A | E1 | E2 | E3 | E4 | E5 | E6 | E7 | E8 | — |
| DP-510 | 750A | 1A、5A | F1 | F2 | F3 | F4 | F5 | F6 | F7 | F8 | F9 |
| DP-510 | 800A | 1A、5A | E1 | E2 | E3 | E4 | E5 | E6 | E7 | E8 | E9 |
| DP-510 | 1000A | 1A、5A | F1 | F2 | F3 | F4 | F5 | F6 | F7 | F8 | F9 |
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
