600A to 1000A Bridge Rectifier Modules
Home Products Diode Bridge ModuleSingle and 3 phase Diode Bridge module600A to 1000A Bridge Rectifier Modules
Product Details
600A to 1000A Bridge Rectifier Modules
Three phase
| VRSM | IDAV(Tcase= 100℃) | ||
| VRRM | 600A | 800A | 1000A |
| 600V | MDS-600-06F2 | MDS-800-06F2 | MDS-1000-06F2 |
| 800V | MDS-600-08F2 | MDS-800-08F2 | MDS-1000-08F2 |
| 1200V | MDS-600-12F2 | MDS-800-12F2 | MDS-1000-12F2 |
| 1400V | MDS-600-14F2 | MDS-800-14F2 | MDS-1000-14F2 |
| 1600V | MDS-600-16F2 | MDS-800-16F2 | MDS-1000-16F2 |
| 1800V | MDS-600-18F2 | MDS-800-18F2 | MDS-1000-18F2 |
Single phase
| VRSM | IDAV(Tcase= 100℃) | ||
| VRRM | 600A | 800A | 1000A |
| 600V | MDQ-600-06F2 | MDQ-800-06F2 | MDQ-1000-06F2 |
| 800V | MDQ-600-08F2 | MDQ-800-08F2 | MDQ-1000-08F2 |
| 1200V | MDQ-600-12F2 | MDQ-800-12F2 | MDQ-1000-12F2 |
| 1400V | MDQ-600-14F2 | MDQ-800-14F2 | MDQ-1000-14F2 |
| 1600V | MDQ-600-16F2 | MDQ-800-16F2 | MDQ-1000-16F2 |
| 1800V | MDQ-600-18F2 | MDQ-800-18F2 | MDQ-1000-18F2 |
