Product Details

Variable Vacuum Capacitors

GREEGOO Type	COMET Old Type	COMET New Type	Capacitance (PF)	Peak Test Voltage (kv)	HF Peak Working Voltage (kv)	Max RF Current (A)	Diameter (mm)	Length (mm)
GVCB50/25/63	CV2C-50E/35	CVZV-50AC/35-BAA	50	35	21	63	71.8	160
GVCB75/32/79	CV3C-75E/45	CVNA-75AC/45-AAA	75	45	32	79	119	196
GVCB100/10/54	CV1C-100UC	CVUN-100AC/15-BAJA	100	15	9	54	55	133.5
GVCB100/10/65(Ⅰ)	CV1C-100J/15	CVZV-100AC/15-BJC-M	100	15	9	65	62	168
GVCB250/10/57	CV1C-250J	CVBA-250AC/15-BEA-L	250	15	9	57	55	148.3
GVCB250/15/94N1	CV1C-250UC	CVUN-250AC/15-BAJA	250	15	9	94	55	133.5
GVCB250/28/138	CV2C-250E/40	CVSA-250AC/40-AAB	250	40	24	138	143	244
GVCB250/35/220	CV3C-250E/50	CVMA-250AC/50-AAB	250	50	30	137	185	302
GVCB250/38/220	CV3C-650E/55	CVMA-650AC/55-AAB-F	250	55	33	137	185	302
GVCB400/5.5/80	CV1C-400EW/7.5	CVMI-400AC/7.5-AAC-M	400	7.5	4.5	80	87.4	190
GVCB450/28/138	CV2C-450G/40	CVSA-450AC/40-ADB	450	40	24	138	143	244
GVCB500/3.5/57	CV05C-500W/5	CVBA-500/BC/5-BEA-L	500	5	3	57	55	148.3
GVCB500/3.5/57(Ⅰ)	CV05C-500N/5	CVBA-500AC/5-BFA-M	500	5	3	57	55	148.1
GVCB500/5.6/92		CVUN-500AC/8-BEJA-Z	500	8	4.8	92	55	134.1
GVCB500/7/86	CV1C 500 NM/10	CVMN-500BC/10-BEC	500	10	6	86	86	132
GVCB500/8.4/94	CV1C-500UCD	CVUN-500BC/12-BAJA	500	12	7.2	94	64	133.5
GVCB500/10/67	CV1C-500UIHN/15	CVMI-500BC/15-BEDA-BL	500	15	9	67	86	194
GVCB500/10/67(I)	CV1C-500EW/15	CVMI-500AC/15-AAC-M	500	15	10	67	86	190.7
GVCB500/10/67(II)	CV1C-500Y/15	CVMI-500BC/15-BAC-L	500	15	10	67	86	191
GVCB500/10/67（Ⅲ）	CV1C-500W/15	CVMI-500BC/15-ACC-L	500	15	10	67	86	191
GVCB500/10/67（Ⅳ）	CV1C-500U/15	CVMI-500BC/15-BEC-L	500	15	9	67	86	194
GVCB500/10/69	CV1C-500T/15	CVVE-500AC/15-BCA-M	500	15	9	69	86	202
GVCB500/10/100(Ⅰ)	CV1C-500T/15	CVVE-500AC/15-BCA-M	500	15	9	100	86	202
GVCB500/10/123	CV1C-500ZMN	CVPO－500BC/15－BECA	500	15	9	123	88	141.5
GVCB500/17.5/170	CV1C-500I/25	CVMX-500AC/25-BEAC-J	500	25	15	170	117	158.7
GVCB500/17.5/170(Ⅰ)		CMVX-500AC/25-BUAA-J1	500	25	15	170	117	164.7
GVCB650/3.5/63(Ⅰ)	CV05C-650N/5	CVDU-650CC/5-DEF	650	5	3	63	44.7	114.3
GVCB650/35/240	CV3C-650E/50	CVMA-650AC/50-AAB-F	650	50	30	240	185	302
GVCBS650/35/730	CV3W-650F/50	CVMA-650FW/50-ABE-F	650	50	35	730	185	420
GVCB750/28/220	CV2C-750E/40	CVMA-750AC/40-AAB	750	40	24	220	185	297
GVCB1000/3.5/70(Ⅰ)	CV05C-1000X/5	CVVI-1000AC/5-ACD-M	1000	5	3	70	70	190.7
GVCB1000/3.5/79	CV05-1000Y/5	CVMI-1000AC-BAC-L	1000	5	3	79	86	180
GVCB1000/3.5/79(Ⅰ)	CV05C-1000W/5	CVMI-1000AC-AAC-L	1000	5	3	79	86	180
GVCB1000/3.5/79（Ⅱ）	CV05C-1000KW/5	CVVI-1000AC/5-KED-M	1000	5	3	79	70	190.7
GVCB1000/3.5/86	CV05C-1000PM/5	CVMN-1000AC/5-BEC	1000	5	3	86	86	132
GVCB1000/3.5/89	CV05C-1000UC	CVUN-1000AC/5-BEJA	1000	5	3	89	55	134.1
GVCB1000/10/80(Ⅰ)	CV1C-1000EW/15	CVNA-1000DC/15-AAA-F	1000	15	9	80	115	206
GVCB1000/10.5/175	CV1C-1000V	CVMX-1000AC/15-BEAA	1000	15	9	175	117	152.2
GVCB1000/21/215	CV2C-1000E	CVMA-1000AC/35-AAB	1000	30	21	215	183	297
GVCB1000/28/225	CV2C-1000E/40	CVMA-1000AC/40-AAB	1000	40	24	225	183	297
GVCB1000/35/250	CV3C-1000E	CVLA-1000AC/50-AAB	1000	50	30	250	208	370
GVCBS1000/35/843	CV3W-1000JB/50	CVLA-1000CW/50-ABE-N	1000	50	30	843	210	478
GVCBS1300/35/1085	CV3W-1300FB/50	CVLA-1300AW/50-ABE-HN	1300	50	30	1085	210	554
GVCB1400/2.1/63	CV03C 1400E	CVZV-1400AC/3-BEA	1400	3	1.8	63	55	141.5
GVCB1500/3.5/60	CV05C-1500H/5	CVVI-1500AC/5-EKA-M	1500	5	3	60	70	190.7
GVCB1500/3.5/65	CV05C-1500N/5	CVVI-1500AC/5-ACD-M	1500	5	3	65	70	190.7
GVCB1500/3.5/84	CV05C-1500D/5	CVZV-1500AC/5-AAA	1500	5	3	84	70	197
GVCB1500/3.5/127	CV05C-1500PMN	CVPO－1500BC/5－BECA	1500	5	3	127	88	131
GVCB1500/10/108	CV1C-1500EW/15	CVSA-1500AC/15-AAB	1500	15	9	108	142.5	250
GVCB1500/24/220	CV2C-1500E/40	CVMA-1500AC/40-AAB	1500	40	24	136	182	354
GVCB1500/24/220(Ⅰ)	CV2C-1500F/40	CVMA-1500AC/40-ADM	1500	40	24	136	182	354
GVCBF1500/24/220	CV2A-1500E/35	CVMA-1500AA/35-AAB	1500	35	21	220	183	354
GVCBS1600/28/790	CV3W-1600E/40	CVLA-1600BW/40-AAE-HN	1600	40	24	633	212	635
GVCB2000/3.5/63	CVO5C-2000SIHN/5	CVMI-2000AC/5-BEDA-BL	2000	5	3	63	86	180
GVCB2000/3.5/114	CV05C-2000M	CVPO－2000BC/5－BEC－L	2000	5	3	114	88	147
GVCB2000/5.6/171		CVMX-2000BC/8-BEAC-J	2000	8	4.8	171	117	152.2
GVCB2000/25/220	CV2C-2000E/35	CVLA-2000AC/35-AAB	2000	35	21	136	212	368

Application and features

Variable vacuum capacitors integrate cutting-edge technology and advanced manufacturing processes to meet the stringent requirements of the semiconductor, flat panel display, broadcast, and industrial markets. Their key features are summarized as follows: Extended operational lifespan, Availability of customized design solutions and Superior RF performance characteristics. These features ensure that variable vacuum capacitors provide stable and efficient capacitance tuning solutions in various demanding environments.

FAQ

Q:What's the benefit of a Vacuum Capacitor? What is a Vacuum Capacitor?

Vacuum capacitors are capacitors with a vacuum as the dielectric, featuring low loss and high voltage resistance, making them suitable for high-frequency and high-voltage applications. They are commonly used in RF and microwave equipment, such as broadcast transmitters and radar systems. The main advantages of vacuum capacitors include high reliability and efficiency, as their low loss characteristics reduce energy waste. Additionally, they maintain stable performance under temperature and frequency variations, ensuring stable operation of equipment. Due to their high temperature and voltage resistance, vacuum capacitors have a long lifespan, reducing maintenance costs. They are widely applicable in various high-frequency and high-power applications, meeting users' needs for high performance and reliability.
