Application and features
Fixed Vacuum Capacitor
Fixed vacuum capacitors utilize vacuum as their dielectric medium, with high-performance ceramic as the encapsulation material, featuring high voltage tolerance, compact design, high quality factor (Q value), stable performance, high reliability, and cost-efficiency. These capacitors play a pivotal role in various high-end application domains, such as induction heating, medium frequency heating, communication transmitters, and broadcasting sectors, among others.
Product Details
|
Type |
COMET
Old Type |
COMET
New Type |
Capacitance
(PF) |
Peak
Test Voltage (kv) |
RF Peak
Working Voltage (kv) |
Max
RF Current
(A)
|
Diameter
(mm) |
Length
(mm) |
| GVC50/9/27 | MC1C-50E/15 | CFMN-50CAC/15-AF-G | 50 | 15 | 9 | 27 | 47 | 62 |
| GVC80/10/43 | MC1C-80E/15 | CFMN-80CAC/15-AF-G | 80 | 15 | 9 | 43 | 48 | 62 |
| GVC90/10/48 | MC1C-90E/15 | CFMN-90CAC/15-AF-G | 90 | 15 | 9 | 48 | 48 | 62 |
| GVC100/10/54 | MC1C100E/15 | CFMN-100CAC/15-AF-G | 100 | 15 | 9 | 54 | 48 | 62 |
| GVC100/25/126 | MC3C-100E/35 | CFMN-100EAC/35-DH-G | 100 | 35 | 21 | 126 | 64 | 87 |
| GVC120/10/65 | MC1C-120E/15 | CFMN-120CAC/15-AF-G | 120 | 15 | 9 | 65 | 48 | 62 |
| GVC130/10/70 | MC1C-130E/15 | CFMN-130CAC/15-AF-G | 130 | 15 | 9 | 70 | 48 | 62 |
| GVC140/10/76 | MC1C-140E/15 | CFMN-140CAC/15-AF-G | 140 | 15 | 9 | 76 | 48 | 62 |
| GVC150/10/81 | MC1C-150E/15 | CFMN-150CAC/15-AF-G | 150 | 15 | 9 | 81 | 48 | 62 |
| GVC175/25/168 | MC3C-175E/35 | CFMN-175EAC/35-DH-G | 175 | 35 | 21 | 168 | 64 | 87 |
| GVC180/10/97 | MC1C -180E/15 | CFMN-180CAC/15-AF-G | 180 | 15 | 9 | 97 | 48 | 62 |
| GVC200/10/107 | MC1C -200E/15 | CFMN-200CAC/15-AF-G | 200 | 15 | 9 | 107 | 48 | 62 |
| GVC210/10/113 | MC1C -210E/15 | CFMN-210CAC/15-AF-G | 210 | 15 | 9 | 113 | 48 | 62 |
| GVC250/10/134 | MC1C -250E/15 | CFMN-250AAC/15-DE-G | 250 | 15 | 9 | 134 | 48 | 52 |
| GVC260/10/132 | MC1C -260E/15 | CFMN-260AAC/15-DE-G | 260 | 15 | 9 | 132 | 48 | 52 |
| GVC350/10/132 | MC05C -350E/15 | CFMN-350AAC/15-DE-G | 350 | 15 | 9 | 132 | 48 | 52 |
| GVC450/33/170 | CF3C-450F/55 | CFZV-450AAC/55-HC-G | 450 | 55 | 33 | 223 | 145.5 | 140 |
| GVC500/8.5/126 | MC05C-500E/12 | CFMN-500AAC/12-DE-G | 500 | 12 | 7.2 | 126 | 48 | 52 |
| GVC750/7/116 | MC05C -750E/10 | CFMN-750AAC/10-DE-G | 750 | 10 | 6 | 116 | 48 | 52 |
| GVC1000/5.6/115 | MC05C -1000E/8 | CFMN-1000AAC/8-DE-G | 1000 | 8 | 4.8 | 115 | 48 | 52 |
| GVC1000/17.5/271 | CF1C-1000H/25 | CFSA-1000DAC/25-GC-G | 1000 | 25 | 15 | 271 | 142.5 | 97 |
| GVC1000/28/162 | CF2C-1000E/40 | CFNA-1000BAC/40-KB-G | 1000 | 40 | 24 | 162 | 115 | 230 |
| GVC1000/35/350(Ⅰ) | CF3C-1000E/50 | CFMA-1000AAC/50-BC-G | 1000 | 50 | 30 | 296 | 180.5 | 158 |
| GVC1500/10/190 | CF1C-1500F/15 | CFSA-1500AAC/15-HC-G | 1500 | 15 | 9 | 190 | 142.5 | 84 |
| GVC1500/25/400 | CF2C-1500E/35 | CFMA-1500AAC/35-BC-G | 1500 | 35 | 21 | 303 | 180.5 | 158 |
| GVC2000/10/200 | CF1C-2000E/15 | CFSA-2000AAC/15-CA-G | 2000 | 15 | 9 | 200 | 142.5 | 84 |
| GVC2000/24/266 | CF2C-2000E/35 | CFMA-2000AAC/35-BC-G | 2000 | 35 | 21 | 266 | 185 | 158 |
| GVC2000/33/400 | CF3C-2000F/55 | CFLA-2000AAC/55-PC-G | 2000 | 55 | 33 | 283 | 210 | 210 |
| GVC2500/17/246 | CF2C-2500E/30 | CFMA-2500AAC/30-BC-G | 2500 | 30 | 18 | 246 | 185 | 158 |
