Single Phase Wi-Fi Smart Energy Meter

This WIFI din rail smart energy meter measures single-phase two-wire AC active energy and other parameters. It has WIFI for remote reading and control through an app. It follows WIFI 802.11b/g/n standards. The meter is durable, stable, can handle high loads, has low power loss, and is compact. It's made according to international standards IEC62052-11 and IEC62053-21 for electricity metering and active energy meters of accuracy class 1.

Specification
Model GSM5188
Meter Type Wifi IVAP
Rate Frequency 50Hz or 60Hz
Rated Current 5(80)A
Rated Voltage 120V/220V/230V/240V
Limits Voltage Range 85~300V(L-N)
Accuracy Class 1
LCD Display kWh 999999.99kWh
Starting Current 40mA (minimum measurement)
Voltage Circuit Power Loss <2W/10VA
WIFI 802.11b/g/n, only supports 2.4GHz network, does not support 5GHz network
Operation Temperature -25~70℃
Relay Control Meter relay signal output to control the AC contactor for on/off

(Note: The meter has options with relay function and without relay function to select from)
