JSZY16-10R
Home Products Voltage & Current TransformerVoltage Transformer with Fuse ProtectionJSZY16-10R
Product Details
JSZY16-10R
| Model |
Rated voltage ratio
KV
|
Accuracy class | Rated capacity VA |
Rated secondary capacity
VA
|
Rated insulation level
KV
|
||
| 0.2 | 0.5 | 1.0 | |||||
| JSZY16-10R | 10/ √ 3/0.1/ √ 3/0.1/ √ 3/0.1/3 | 0.2/0.5/6P | 15 | 25 | 50 | 400 | 12/42/75 |
| 10/ √ 3/0.1/ √ 3/0.22/ √ 3/0.1/3 | 0.5/0.5/6P | ||||||
