GVC3-800/1000/1250A 2 pole vacuum contactors
Home Products Vacuum Contactor1.14KV Low Voltage Vacuum ContactorsGVC3-800/1000/1250A 2 pole vacuum contactors
Product Details
GVC3-800/1000/1250A 2 pole vacuum contactors
Name | Unit | Value | |||||
Main circuit | Rated working voltage (Ue) | V | 1140 | ||||
Rated working current (Ie) | A | 800, 1000,1250 | |||||
Rated thermal current (Ith) | A | 800, 1000,1250 | |||||
Rated frequency (fr) | Hz | 50~60 | |||||
Rated making capacity | A | 4Ie(AC2) | |||||
Rated breaking capacity | A | 4Ie (AC2) | |||||
Power frequency withstand voltage | Between phases, phase to earth | kV | 4.2 | ||||
Vacuum breaks | kV | 10 | |||||
Lightening impulse withstand voltage | kV | 8 | |||||
Control circuit | Rated voltage1 (Us) | V | AC. Or DC | ||||
110/220/380 | |||||||
Rated power (Ps) | Electric holding | VA | ≤1000/100 (absorbing/holding) | ||||
Auxiliary circuit | Form | 3a 3b | |||||
Rated value | AC380V/5A, DC380V/1A | ||||||
Control circuit, auxiliary circuit to earth power frequency withstand voltage | kV | 2 | |||||
Rated operating frequency | Long-term or mechanical holding type | time/h | 300 | ||||
Short-term | time/h | 600 | |||||
Mechanical endurance2 | 10000 times | 30 | |||||
Electrical endurance | 10000 times | 10 | |||||
Mechanical characteristics | Closing time | ms | ≤200 | ||||
Original opening time | ms | ≤160 | |||||
3-phase synchronism | ms | ≤3 | |||||
Closing tripping | ms | ≤10 | |||||
Remark: 1.rated control voltage can be made according to customer’s requirements. | |||||||
2.for mechanical holding type, the interlock mechanism should be changed every 300,000 times. |
