Product Details
D355 stud rectifier diode
Feature
- Hermetic metal case
- High surge current capabilities
- Stud cathode and stud anode version
Typical Applications
- Converters
- Power supplies
- Machine tool controls
| Type number | Voltage Code | VRRM, maximum repetitive peak reverse voltage |
VRSM , maximum non- repetitive peak rev. voltage |
IRRM max. @ TJ = TJ max. |
| D355N/R-16/18/20 | V | V | mA | |
| 16 | 1600 | 1700 | 15 | |
| 18 | 1800 | 1900 | ||
| 20 | 2000 | 2100 |
| Parameters | D355 | Units | |
| IF(AV) | 355 | A | |
| @ Ths | 100 | oC | |
| IF(RMS) | 595 | A | |
| IFSM | @ 50Hz | 6050 | A |
| @ 60Hz | 6335 | A | |
| I2t | @ 50Hz | 183 | KA2S |
| @ 60Hz | 167 | KA2S | |
| VRRM range | 1600 to 2000 | V | |
| TJ | -40 to 180 | oC | |
