Avalanche Rerctifier Diode DL222
Home Products Stud Rectifier DiodeAvalanche DiodesAvalanche Rerctifier Diode DL222
Product Details
Avalanche Rerctifier Diode DL222
| Type | IRRM | IF(AV) | IFRSM | IFSM | I2t | VFM/IFM | TTO | PRSM | rT | Rth(j-c) | M2 | Wt | Outline |
| TC,℃ | 10ms | 10ms | 100mks | ||||||||||
| mA | A | A | kA | A2S103 | V/A | V | kW | mΩ | ℃/W | N/m | kg | ||
| DL222-32 | 8 | 32 | 50 | 0.46 | 1.06 | 1.35/100 | 0.85 | 3 | 5 | 0.95 | 1.4-1.8 | 0.012 | RSD2 |
| DL222-40 | 8 | 40 | 62 | 0.55 | 1.51 | 1.35/125 | 0.85 | 3 | 4 | 0.8 | 1.4-1.8 | 0.012 |
