MD25 MD40 MD60 MD80 MD100 MD110 Anti-reverse Diode Modules
Anti-reverse diode modules (also known as blocking or anti-backflow modules) are crucial components used in solar PV systems, battery charging circuits, and DC power setups. They ensure current flows exclusively in one direction, preventing battery back-feeding into solar panels during overcast conditions or protecting delicate upstream circuitry against accidental reverse-polarity connections.
| Part numbers | IF(AV) | Tc |
VRRM |
| MD25-04 | 25A | 100℃ | 400V |
| MD25-06 | 25A | 100℃ | 600V |
| MD25-08 | 25A | 100℃ | 800V |
| MD25-10 | 25A | 100℃ | 1000V |
| MD25-12 | 25A | 100℃ | 1200V |
| MD25-16 | 25A | 100℃ | 1600V |
| MD25-18 | 25A | 100℃ | 1800V |
| MD25-20 | 25A | 100℃ | 2000V |
| MD25-25 | 25A | 100℃ | 2500V |
| MD40-04 | 40A | 100℃ | 400V |
| MD40-06 | 40A | 100℃ | 600V |
| MD40-08 | 40A | 100℃ | 800V |
| MD40-10 | 40A | 100℃ | 1000V |
| MD40-12 | 40A | 100℃ | 1200V |
| MD40-16 | 40A | 100℃ | 1600V |
| MD40-18 | 40A | 100℃ | 1800V |
| MD40-20 | 40A | 100℃ | 2000V |
| MD40-25 | 40A | 100℃ | 2500V |
| MD60-04 | 60A | 100℃ | 400V |
| MD60-06 | 60A | 100℃ | 600V |
| MD60-08 | 60A | 100℃ | 800V |
| MD60-10 | 60A | 100℃ | 1000V |
| MD60-12 | 60A | 100℃ | 1200V |
| MD60-16 | 60A | 100℃ | 1600V |
| MD60-18 | 60A | 100℃ | 1800V |
| MD60-20 | 60A | 100℃ | 2000V |
| MD60-25 | 60A | 100℃ | 2500V |
| MD80-04 | 80A | 100℃ | 400V |
| MD80-06 | 80A | 100℃ | 600V |
| MD80-08 | 80A | 100℃ | 800V |
| MD80-10 | 80A | 100℃ | 1000V |
| MD80-12 | 80A | 100℃ | 1200V |
| MD80-16 | 80A | 100℃ | 1600V |
| MD80-18 | 80A | 100℃ | 1800V |
| MD80-20 | 80A | 100℃ | 2000V |
| MD80-25 | 80A | 100℃ | 2500V |
| MD100-04 | 100A | 100℃ | 400V |
| MD100-06 | 100A | 100℃ | 600V |
| MD100-08 | 100A | 100℃ | 800V |
| MD100-10 | 100A | 100℃ | 1000V |
| MD100-12 | 100A | 100℃ | 1200V |
| MD100-16 | 100A | 100℃ | 1600V |
| MD100-18 | 100A | 100℃ | 1800V |
| MD100-20 | 100A | 100℃ | 2000V |
| MD100-25 | 100A | 100℃ | 2500V |
| MD110-04 | 110A | 100℃ | 400V |
| MD110-06 | 110A | 100℃ | 600V |
| MD110-08 | 110A | 100℃ | 800V |
| MD110-10 | 110A | 100℃ | 1000V |
| MD110-12 | 110A | 100℃ | 1200V |
| MD110-16 | 110A | 100℃ | 1600V |
| MD110-18 | 110A | 100℃ | 1800V |
| MD110-20 | 110A | 100℃ | 2000V |
| MD110-25 | 110A | 100℃ | 2500V |
