MD200 MD250 MD300 MD400 MD500 MD600 Anti-reverse Diode Modules
Anti-reverse diode modules (also known as blocking or anti-backflow modules) are crucial components used in solar PV systems, battery charging circuits, and DC power setups. They ensure current flows exclusively in one direction, preventing battery back-feeding into solar panels during overcast conditions or protecting delicate upstream circuitry against accidental reverse-polarity connections.
| Part numbers | IF(AV) | Tc |
VRRM |
| MD200-04 | 200A | 100℃ | 400V |
| MD200-06 | 200A | 100℃ | 600V |
| MD200-08 | 200A | 100℃ | 800V |
| MD200-10 | 200A | 100℃ | 1000V |
| MD200-12 | 200A | 100℃ | 1200V |
| MD200-16 | 200A | 100℃ | 1600V |
| MD200-18 | 200A | 100℃ | 1800V |
| MD200-20 | 200A | 100℃ | 2000V |
| MD200-25 | 200A | 100℃ | 2500V |
| MD200-30 | 200A | 100℃ | 3000V |
| MD200-40 | 200A | 100℃ | 4000V |
| MD200-50 | 200A | 100℃ | 5000V |
| MD250-04 | 250A | 100℃ | 400V |
| MD250-06 | 250A | 100℃ | 600V |
| MD250-08 | 250A | 100℃ | 800V |
| MD250-10 | 250A | 100℃ | 1000V |
| MD250-12 | 250A | 100℃ | 1200V |
| MD250-16 | 250A | 100℃ | 1600V |
| MD250-18 | 250A | 100℃ | 1800V |
| MD250-20 | 250A | 100℃ | 2000V |
| MD250-25 | 250A | 100℃ | 2500V |
| MD250-30 | 250A | 100℃ | 3000V |
| MD250-40 | 250A | 100℃ | 4000V |
| MD250-50 | 250A | 100℃ | 5000V |
| MD300-04 | 300A | 100℃ | 400V |
| MD300-06 | 300A | 100℃ | 600V |
| MD300-08 | 300A | 100℃ | 800V |
| MD300-10 | 300A | 100℃ | 1000V |
| MD300-12 | 300A | 100℃ | 1200V |
| MD300-16 | 300A | 100℃ | 1600V |
| MD300-18 | 300A | 100℃ | 1800V |
| MD300-20 | 300A | 100℃ | 2000V |
| MD300-25 | 300A | 100℃ | 2500V |
| MD300-30 | 300A | 100℃ | 3000V |
| MD300-40 | 300A | 100℃ | 4000V |
| MD300-50 | 300A | 100℃ | 5000V |
| MD400-04 | 400A | 100℃ | 400V |
| MD400-06 | 400A | 100℃ | 600V |
| MD400-08 | 400A | 100℃ | 800V |
| MD400-10 | 400A | 100℃ | 1000V |
| MD400-12 | 400A | 100℃ | 1200V |
| MD400-16 | 400A | 100℃ | 1600V |
| MD400-18 | 400A | 100℃ | 1800V |
| MD400-20 | 400A | 100℃ | 2000V |
| MD400-25 | 400A | 100℃ | 2500V |
| MD400-30 | 400A | 100℃ | 3000V |
| MD400-40 | 400A | 100℃ | 4000V |
| MD400-40 | 400A | 100℃ | 5000V |
| MD500-04 | 500A | 100℃ | 400V |
| MD500-06 | 500A | 100℃ | 600V |
| MD500-08 | 500A | 100℃ | 800V |
| MD500-10 | 500A | 100℃ | 1000V |
| MD500-12 | 500A | 100℃ | 1200V |
| MD500-16 | 500A | 100℃ | 1600V |
| MD500-18 | 500A | 100℃ | 1800V |
| MD500-20 | 500A | 100℃ | 2000V |
| MD500-25 | 500A | 100℃ | 2500V |
| MD500-30 | 500A | 100℃ | 3000V |
| MD500-40 | 500A | 100℃ | 4000V |
| MD500-50 | 500A | 100℃ | 5000V |
| MD600-04 | 600A | 100℃ | 400V |
| MD600-06 | 600A | 100℃ | 600V |
| MD600-08 | 600A | 100℃ | 800V |
| MD600-10 | 600A | 100℃ | 1000V |
| MD600-12 | 600A | 100℃ | 1200V |
| MD600-16 | 600A | 100℃ | 1600V |
| MD600-18 | 600A | 100℃ | 1800V |
| MD600-20 | 600A | 100℃ | 2000V |
| MD600-25 | 600A | 100℃ | 2500V |
| MD600-30 | 600A | 100℃ | 3000V |
| MD600-40 | 600A | 100℃ | 4000V |
| MD600-50 | 600A | 100℃ | 5000V |
Need more information?
Contact us to request pricing, availability and customization options.
