Overview
LMZP-10
LMZP-10 heart-type runway-shaped window current transformer(also known as high-precision current transformer) is suitable for electric energy measurement, high-accuracy limit value protection and current measurement of the 10kV~35kV power system for AC power systems.
Product Details
| Model | Application | Measuring CT | Protection CT | Double winding CT | |||||||
|
Rated primary
current
|
Accuracy & rated capacity VA
|
Accuracy & rated capacity VA
|
Accuracy & rated capacity VA
|
||||||||
| 0.2S | 0.2 | 0.5 | 10P10 | 10P15 | 10P20 | 0.2S | 0.5 | 10P15 | 10P10 | ||
| LMZP-10 | 50 | / | / | 2.5 | 2.5 | / | / | / | / | / | / |
| 100 | / | / | 3.75 | 3.75 | 2.5 | / | / | 2.5 | / | 2.5 | |
| 150 | / | / | 5 | 3.75 | 2.5 | / | / | 2.5 | / | 2.5 | |
| 200 | / | 2.5 | 5 | 5 | 2.5 | / | / | 2.5 | / | 2.5 | |
| 300 | / | 3.8 | 5 | 7.5 | 5 | 2.5 | / | 3.75 | / | 3.75 | |
| 400 | / | 5 | 10 | 7.5 | 5 | 2.5 | / | 5 | 2.5 | 5 | |
| 500 | 5 | 5 | 10 | 10 | 5 | 2.5 | / | 5 | 2.5 | 5 | |
| 600 | 5 | 5 | 10 | 10 | 5 | 3.75 | / | 5 | 2.5 | 5 | |
| 800 | 5 | 5 | 10 | 15 | 10 | 5 | / | 7.5 | 5 | 7.5 | |
| 1000 | 10 | 15 | 20 | 15 | 10 | 5 | / | 10 | 5 | 10 | |
| 1200 | 10 | 15 | 20 | 15 | 10 | 5 | / | 10 | 5 | 10 | |
