Direct 100A Modbus-RTU 1 Module Din Rail KWH Meter
Home Products Building Protection DeviceModular KWH Meter Single PhaseDirect 100A Modbus-RTU 1 Module Din Rail KWH Meter
Specification
Direct 100A Modbus-RTU 1 Module Din Rail KWH Meter
| Model | GEM015SD (LCD Display) |
| Reference Voltage(Un) | 120V 230V 240V |
| Operating Voltage | 181/279V AC(3~) |
| Rated Current(Ib) | 2.55A 10A 15A 20A 30A |
| Maximum Current (Imax) | 10A 20A 40A 60A 80A 100A |
| Starting Current | ≤0.004b(Direct Access) |
| Withstand Overload Current | 30lmax 0.01s |
| Working Frequency | 50Hz±10% |
| Internal Power Consumption | ≤2W/10VA |
| Pulse Constant | 1000imp |
| RS485 Port | 23(A)and 24(B) |
| Data Storage Time | >20 Years |
