XM18 proximity switch
Home Products Proximity Photoelectric SensorLinear Proximity SwitchXM18 proximity switch
Product Details
XM18 proximity switch
|
Outward appearance code |
XM18 |
||
|
Detectable object |
metal |
||
|
Detection distance |
FLush type:5mm |
Non-fulsh:8mm |
|
|
Model avalible |
Current type |
XM18-3005PMI |
XM18-3008PMI |
|
Voltage type |
XM18-3005PMU |
XM18-3008PMU |
|
|
Voltage range |
15~30VDC |
||
|
Consumption |
At the time of detection |
≤200mA…＜4mA |
|
|
At the time of non-detection |
≤20mA |
||
|
Loading resistance |
Current type |
0~300Ω |
|
|
Voltage type |
≥2.2KΩ |
||
|
Output |
Current type |
4-20mA |
|
|
Voltage type |
0-5V/ 0-10V |
||
|
Allowable voltage undulation |
≤5% |
||
|
Output signal |
PNP simulation |
||
|
Linear error |
±5% |
||
|
Ambient tempertaure |
-10°C~ 70°C |
||
|
Shell material |
Plastic.metal |
||
|
Protection grade |
IP54 |
||
