Three phase 4 wire wifi smart energy meter

This WIFI din rail smart energy meter can measure three-phase four-wire AC active energy and other parameters. It supports WIFI communication and can be remotely read and controlled via a mobile app. It complies with the WIFI 802.11b/g/n standard. This meter has a long service life, good stability, high overload capacity, low power consumption, and a compact size. It is manufactured in accordance with the international standards IEC62052-11 and IEC62053-21, meeting the Class 1 accuracy requirements for static active energy meters.

Specification
Model GSM1250
Meter Type Wifi IVAP
Rate Frequency 50Hz or 60Hz
Rated Current 3x5(30)A / 3x10(40)A / 3x15(60)A / 3x20(80)A / 3x30(100)A
Rated Voltage 3x220/380V / 3x230/400V
Limits Voltage Range 85-300V(L-N)
Accuracy Class 1
LCD Display kWh 999999.99kWh
Starting Current 40mA (minimum measurement)
Voltage Circuit Power Loss <2W/10VA
WIFI 802.11b/g/n, only supports 2.4GHz network, does not support 5GHz network
Operation Temperature -25~70℃
Relay Control Meter relay signal output to control the AC contactor for on/off
(Note: The meter has options with relay function and without relay function)
