Single phase bridge rectifier QL 20/40/60A
Home Products Bridge RectifierSingle phase bridge rectifier (Fast-on type)Single phase bridge rectifier QL 20/40/60A
Product Details
Single phase bridge rectifier QL 20/40/60A
Type | I F | V F | V RRM | I RRM1 | I RRM2 | I FSM | Tj | Tstg | Gooling |
A | V | V | mA | mA | A | ℃ | ℃ | ||
QL12 | 20 | 1.4 | 100-1400 | 0.04 | 0.4 | 210 | -40~ 125 | -40~ 130 | air gooling |
QL14 | 40 | 1.4 | 100-1400 | 0.07 | 0.8 | 360 | -40~ 125 | -40~ 130 | air gooling |
QL16 | 60 | 1.4 | 100-1400 | 0.1 | 2 | 540 | -40~ 125 | -40~ 130 | air gooling |
