LMZ(J)1-30A 0.5KV Current Transformer
| Model | Ratio A | Burden VA | ||||
| Class 0.5 | Class 0.5s | Class 0.2 | Class 0.2s | Cross core turn number | ||
| LMZJ1-30A 0.5KV | 5/5 | 5 | 5 | 5 | 5 | 30 |
| 10/5 | 5 | 5 | 5 | 5 | 15 | |
| 15/5 | 5 | 5 | 5 | 5 | 10 | |
| 20/5 | 5 | 5 | 5 | 5 | 10 | |
| 25/5 | 5 | 5 | 5 | 5 | 6 | |
| 30/5 | 5 | 5 | 5 | 5 | 5 | |
| 40/5 | 5 | 5 | 5 | 5 | 5 | |
| 50/5 | 5 | 5 | 5 | 5 | 3 | |
| 75/5 | 5 | 5 | 5 | 5 | 2 | |
| 75/5 | 5 | 5 | 5 | 5 | 1 | |
| 100/5 | 5 | 5 | 5 | 5 | 2 | |
| 100/5 | 5 | 5 | 5 | 5 | 1 | |
| 150/5 | 5 | 5 | 5 | 5 | 1 | |
| 200/5 | 5 | 5 | 5 | 5 | 1 | |
| 250/5 | 5 | 5 | 5 | 5 | 1 | |
| 300/5 | 5 | 5 | 5 | 5 | 1 | |
