Product Details
Inductive proximity sensor LM34
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LM34-3017NA | 17mm | DC6-36V | NPN | NO | Non-flush |
| LM34-3017NB | 17mm | DC6-36V | NPN | NC | Non-flush |
| LM34-3017NC | 17mm | DC6-36V | NPN | NO NC | Non-flush |
| LM34-3017PA | 17mm | DC6-36V | PNP | NO | Non-flush |
| LM34-3014PB | 17mm | DC6-36V | PNP | NC | Non-flush |
| LM34-3017PC | 17mm | DC6-36V | PNP | NO NC | Non-flush |
| LM34-3017LA | 17mm | DC6-36V | Two wire system | NO | Non-flush |
| LM34 -3017LB | 17mm | DC6-36V | Two wire system | NC | Non-flush |
| LM34 -2017A | 17mm | AC90-250V | SCR control lable silicon | NO | Non-flush |
| LM34-2017B | 17mm | AC90-250V | SCR control lable silicon | NC | Non-flush |
| LM34 -2017C | 17mm | AC90-250V | SCR control lable silicon | NO NC | Non-flush |
