SKUT115/12-V2 Three phase antiparallel thyristor module

Features

• Compact design
• Two screws mounting
• Heat ransfer and isolation through direct copper board (Low Rth)
• Low resistance in steady-state and high reliability
• High surge currents
• Glass passivated thyrsitor chips

Typical Applications

• Soft starter
• Light controle.g. studios, theaters)
• Temperature control (e.g. oven, chemical processes)

Remarks

• IRMS=105A, for W3C application, sin. 180° and Ts=85°C
